Data Sheet

Code du produit:

GX-CV728A-28-AI

Résumé:

4K/8MP, 3840x2160@20fps, H.265, DWDR, 0.001Lux, Warm light up to 30m (98ft), Built-in Mic, 2.8mm Fixed Lens, PoE, IP66, Optional: GX-CV-BK80X, GX-CV-BK09D

  • 1/2.8" Sony CMOS sensor
  • 4K resolution 3840 x 2160P
  • Low illumination 0.01Lux
  • Day/Night, AWB/MWB, BLC, HLC, 2D/3D-DNR, Shutter, IR-CUT
  • D-WDR, Mirror, rotate, Defogging
  • Multiply Style OSD Overlay, Motion Detection, Privacy Mask
  • RTSP and Onvif 17.06 compatible with many third-party NVR
  • H.264/H.265 dual-stream media server
  • Easy-to-use P2P Cloud service
  • Support user authentication, video data encryption
  • Support Alarm Snapshot to Email and FTP
  • Multiply WEB browser IE, Firefox 32bit ESR, PC Client, Mobile APP remote access
  • RJ45 100mbps network port, IEEE802.3af PoE
  • Lightning protection 4000V
  • Strong water-proof housing, IP66
  • 2 pcs IR&Warm lights, light distance 20-30 meters
  • F1.6 2.8 mm fixed lens
  • SD slot and reset button

Model

GX-CV728A-28-AI

Camera

Image Sensor

1/2.8" Sony CMOS

Effective Pixels

8 megapixels

Electronic Shutter

AUTO, 1/25s ~ 1/100000s

Min. Illumination

0.01Lux@F1.2(AGC ON), 0Lux IR on

Day/Night

Auto/Color/(B/W)/Timing

WDR

Digital WDR

White Balance

Auto/Manual

BLC /HLC

Support

DNR

2D/3D DNR

Other

AGC,Motion Detection,Privacy Mask,Flip ,OSD overlay

Encode

Video Standard

H.264/H.265

Video Resolution

MainStream:20fps@8MP(3840x2160),30fps@6MP(3072x2048)/5MP(2592x1 944)/4MP/3MP/1080P/720P,etc.

Sub stream: 720x480/VGA(640x480)/360P/QVGA@30fps,etc.

Video Bitrates

512Kbps - 12Mbps, VBR/CBR

Audio Standard

G.711-u/G.711-a

Built-in Mic

Yes

Built-in Speaker

No

Micro SD slot

Yes (Max support 256G card)

Reset

Reset button

Smart Event

Motion detection Human detection

Vehicle detection

Led

Led

2 pcs IR&warm-light Led

Distance

20-30 M

Lens

Focal length

F1.6 2.8mm fixed lens

Network Services

Protocol

HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS, etc.

P2P

Yes

Web

IE , Firefox (32bit esr), etc.

Media

CMS, Android, IOS

ONVIF

17.06 compatible

General

Network Port

1-RJ45, 100Mbps, POE optional

Power Supply

12 VDC ± 10%

Power Consumption

< 8 W

Operating Temp.

-30C-(+60)C, 10%-90%RH
