Data Sheet

Code du produit:

NVSS6102A02

Résumé:

Max 36CH @ 160Mbps Connexions et enregistrement IPC 5M/4M/3M/1080P, 1x HDMI, 1x VGA, 2x SATA, Audio 1in/1out, 1x RJ-45/1000Mbps, USB 5x, POS, RAID 5/6, Surveillance réseau multiple , Bureau à distance

  • Max. 36 Channel 5M / 4M / 3M / 1080P IPC connections and recording
  • HDMI and VGA synchronous output up to 1080P
  • Instant playback, ICON search, 7 Intelligent analysis function
  • 64 channel POS integration
  • Remote Desktop with TeamViewer
  • ONVIF 2.3 conformance
  • Support P2P function, Windows CMS, Mac/Android/iOS NVSS Client

...


System
Main Processor Intel 1037U Dual core CPU
Operating System 32bit Linux OS
Memory 4GB
Video & Audio
Bandwidth Max Input bandwidth: 160Mbps, Max output bandwidth: 160Mbps
Recording 36ch@5M / 4M / 3M / 1080P / 720P / D1
Preview 9ch@5M / 4M / 3M / 1080P / 18ch@720P / 36ch@D1
Playback 9ch@5M / 4M / 3M / 1080P / 16ch@720P / D1
Audio 1ch audio & 1ch Mic in, 1ch audio out
Recording
Recording Mode Manual, Schedule(Continuous, Motion detection, Sensor Alarm), Stop
Alarm Recording Motion detection, External alarm
Backup Mode Network download / USB HDD / Mobile DVD
Display
Video Output 1ch VGA + 1ch HDMI sync video output
Multi-screen Display Main monitor 1/4/6/9/13/16/20/25/33/36 split, sub monitor max 16 split.
HDMI/VGA Output 1920x1080 / 1680x1050 / 1440x900 / 1280x1024 / 1280x720 / 1024x768
General
Network Interface 1x RJ-45 ports(1000M)
Power Supply 12VDC, 5A
Hard Disk 2x SATAII HDD, 6TB for each
USB 5x USB ports(1 side USB 2.0, 4 rear USB 2.0)
Power Consumption Max. 60W (Include HDD)
Working Environment Temperature: 0°C~60°C, Humidity: 10%~80% ( non-condensation)
Dimension W430xD250xH44.5 mm, mini case
Weight 3.5Kg
