Data Sheet

Code du produit:

SVDN8704Q-P4+1TB

Résumé:

40Mbps, 4x6MP@60fps, H.264, 1CH HDMI, 1CH VGA, Audio 1in/1out, 1x SATA up to 6TB/ea, 1x USB2.0, 1x USB3.0, 1x RJ45 10/100/1000M, DC48V, 1U, Toshiba 1TB HDD included

  • Third-Party network cameras supported
  • Up to 6MP resolution recording
  • HDMI and VGA output at up to 1920x1080P resolution
  • Plug & Play with 4 independent PoE network interfaces
  • 1 SATA HDD interface up to 6TB
Video/Audio Input
IP video input 4-ch
Two-way audio input 1-ch, RCA(2.0Vp-p, 1kOhm)
Incoming bandwidth 40Mbps
Outgoing bandwidth 80Mbps
Remote connections 128
Video/Audio output
Recording resolution 6MP
HDMI/VGA output 1-ch, resolution: 1920x1080/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz,
Frame Rate Main Stream: 60fps, Sub Stream: 60fps
Audio output 1-ch, RCA (lINEAR, 1kOhm)
Decoding
Playback resolution 6MP/ 5MP/ 4MP/ 3MP/ 1080P/ UXGA/ 720P/ VGA/ 4CIF/ DCIF/ 2CIF/ CIF/ QCIF
Capability 4-ch
Hard disk
SATA 1 SATA
Capacity Up to 6TB capacity for each HDD
External interface
Network interface 1 RJ-45 10M/100M/1000M self-adaptive Ethernet interface
USB port 1x USB2.0, 1x USB3.0
PoE Interface
Interface 4 independent 100 Mbps PoE
Power </= 50W
Supported standard AF/AT
General
Power Supply 48V DC
Consumption </= 10W
Working temperature 14deg.F ~ 131deg.F (-10deg.C ~ +55deg.C)
Working humidity 10% ~ 90%
Chassis 1U chassis
Dimensions (WxDxH) 12.4" x 9.0" x 1.8" (315 x 230 x 45mm)
Weight </= 4.4lb (2kg)
