Hikvision Radar Device IRS-BVSMR3-H3AG
Hikvision Radar Device IRS-BVSMR3-H3AG
Model: IRS-BVSMR3-H3AG
Prix régulier
$361.00
Prix de vente
$361.00
Prix régulier
Disponible en stock
Open here
- Adopt millimeter-wave radar detection without visual sense, no privacy disclosure
- 24x 7 detection without the influence of illumination and temperature
- Detection of person presence in the bed
- Detection of respiratory rate, heartbeat rate
- Support two-way audio
- Support emergency rope pull alarm function
- Detachable cord for flexibility
Impossible de charger la disponibilité du ramassage
- Adopt millimeter-wave radar detection without visual sense, no privacy disclosure.
- 24x 7 detection without the influence of illumination and temperature.
- Detection of person presence in the bed.
- Detection of respiratory rate, heartbeat rate.
- Support two-way audio.
- Support emergency rope pull alarm function.
- Detachable cord for flexibility
| Radar | |
|---|---|
| Working Frequency | 60 GHz to 64 GHz |
| Modulation Waveform | FMCW |
| Detection Distance | 0.5 m to 1.5 m |
| Scan Bandwidth | 3.5 GHz |
| Distance Resolution | 0.0435 m |
| Horizontal Detection Angle | -25° to 25° |
| Vertical Detection Angle | -10° to 10° |
| Data Period | 50 ms |
| Interface | |
| Power Input | 12 VDC or PoE power supply |
| Alarm Output | Switch volume (without voltage) |
| Communication Interface | Wi-Fi (2.4 G frequency band) RJ45 Ethernet interface |
| Communication Protocol | OTAP protocol |
| General | |
| Working Temperature | -40 °C to 50 °C (-40 °F to 122 °F) |
| Dimensions | 96 mm × 96 mm × 65.26 mm (3.8" × 3.8" × 2.6") (L × W × H) |
| Gross Weight | 439 g |
| Net Weight | 184 g |
| Emergency Cord | 20cm, Detachable |
