Data Sheet

Code du produit:

GX-RTVS-RT29-UHF

Résumé:

Coverage Range 2~5miles (3~8km), Monitor, Scan, Scrambler, Vox, Alarm, Squelch level, High/Middle/Low output Power, IP67 Waterproof, Time-out Timer, CTCSS & DCS, Battery Save Mode, Battery Voltage Prompt, Busy Channel Lockout

  • High-power 10W, communication distance farther
  • High-capacity battery, long standby time
  • The scrambler to ensure the communication confidentiality
  • Coverage Range 2~5miles (3~8km)

* Pre-sale or support line contact: Canada@retevis.com

Frequency Range UHF: 400-480MHz
Channel Number 16
Output power 10W
Working voltage 7.4V DC
Battery capacity 3200mAh(Li-ion)
Dimension(with battery, without antenna) 151x58x38mm(5.9x2.3x1.5in)
Weight(with battery 7 antenna) 335g(11.8oz)
Audio distortion <5%
Frequency stability +/-2.5ppm
Max frequency deviation </=2.5KHz
Spurious emission </=7uW
Modulation mode 11K Dia.F3E
Reference sensibility </=0.3uV
Squelch on sensibility </=0.25uV
Adjacent channel selectivity >/=65dB
Spurious response >/=55dB
International >/=60dB
Current </=1.5A
