Data Sheet

Code du produit:

GX715FSL-AI

Résumé:

5MP, 2880x1620@30fps, Ultra265, Triple Streams, 0,002Lux@F1.2, 120dB WDR, 3D DNR, Day&Night (ICR), IR jusqu'à 131ft (40m), fente pour carte Micro SD, micro intégré, prévention des intrusions, Humain et véhicule, IP67, IK10, Lentille VF motorisée 2,7~13,5 mm, DC12V / PoE

  • Image de haute qualité avec capteur CMOS 5MP, 1/2,7"
  • 5MP (2880*1620)@ 30/25fps ; 4MP (2560*1440)@ 30/25fps; 3MP (2304*1296)@30/25fps; 2MP (1920*1080) @30/25fps
  • Ultra 265, H.265, H.264, MJPE
  • La technologie LightHunter garantit une qualité d'image ultra-élevée dans un environnement à faible éclairage
  • La technologie True WDR de 120 dB permet d'obtenir une image claire dans une scène à forte luminosité
  • Prise en charge du mode couloir 9:16
  • Micro intégré
  • Infrarouge intelligent, jusqu'à 40 m (131 ft) de distance IR
  • Prend en charge les cartes Micro SD 256 G
  • IK10 résistant au vandalisme
  • Protection IP67


Sensor 1/2.7", 5.0 megapixel, progressive scan, CMOS
Lens 2.7 ~ 13.5mm, AF automatic focusing and motorized zoom lens
DORI Distance Lens (2.7mm), Detect (60.8m), Observe (24.3m), Recognize (12.2m), Identify (6.1m)
Lens (13.5mm), Detect (303.8m), Observe (121.5m), Recognize (60.8m), Identify (30.4m),
Angle of view (H) 106.25°~ 30.42°
Angle of View (V) 56.36°~ 17.22°
Angle of View (O) 110.34°~34.18°
Adjustment angle Pan: 0° ~ 360°, Tilt: 0° ~ 75°, Rotate: 0° ~ 360°
Shutter Auto/Manual, 1 ~ 1/100000s
Minimum Illumination Colour: 0.002Lux (F1.2, AGC ON)
0Lux with IR
Day/Night IR-cut filter with auto switch (ICR)
Digital Noise Reduction 2D/3D DNR
S/N >56dB
IR Range Up to 40m (131ft) IR range
Wavelength 850nm
IR On/Off Control Auto/Manual
Defog Digital Defog
WDR 120dB
Video
Video Compression Ultra 265,H.265, H.264, MJPEG
H.264 code profile Baseline profile, Main profile, High profile
Frame Rate Main Stream:5MP (2880*1620), Max 30fps; 4MP (2560*1440), Max 30fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps;
Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
Video Bit Rate 128 Kbps~16 Mbps
OSD Up to 8 OSDs
Privacy Mask Up to 4 areas
ROI Up to 8 areas
Motion Detection Up to 4 areas
White Balance Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Smart IR Support
Flip Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise
Dewarping N/A
HLC Supported
BLC Supported
Audio
Audio Compression G.711
Suppression Supported
Sampling Rate 8KHZ
Storage
Edge Storage Micro SD, up to 256GB
Network Storage ANR
Network
Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS
Compatible Integration ONVIF (Profile S, Profile G, Profile T), API
Client EZStation
EZView
EZLive
Web Browser Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+
Interface
Built-in Mic Supported
Network 1 RJ45 10M/100M Base-TX Ethernet
Certifications
Certifications CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15
General
Power DC 12V±25%, PoE (IEEE 802.3af)
Power consumption: Max 7.0 W
Dimensions (Ø x H) ?129 x 110mm (Ø5.1” x 4.3”)
Net Weight 0.70kg (1.52lb)
Material Metal
Working Environment -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ?95% RH (non-condensing)
Strorage Environment -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ?95% RH (non-condensing)
Surge Protection 6KV
Ingress Protection IP67
vandal resistant IK10
Reset Button Supported

Junction Box

GX-BK-JB80X


Wall Mount

GX-BK-WM02D
