Data Sheet

Code du produit:

TVI-DVR-2208

Résumé:

8CH BNC (TVI / AHD / CVI / CVBS), 4CH IP, jusqu'à 8MP, H.265 / H.264, Audio 1in / 1out, sortie CVBS, 1x VGA, 1x HDMI, 2x SATA jusqu'à 10To / ch, 1x RJ45, 2x USB 2.0, 1x RS485, DC12V

  • Prise en charge des formats vidéo H.265 / H.264
  • Prise en charge des caméras IP avec accès adaptatif TVI, AHD, CVI, CVBS et IP
  • entrée BNC 8 canaux
  • Résolution d'enregistrement jusqu'à 8MP
  • Prend en charge la sortie HDMI 1 canal jusqu'à 4K, la sortie VGA 1 canal jusqu'à 1920 * 1080
  • Longue distance de transmission sur câble coaxial


Video/Audio Input
Analog Video Input 8-ch, BNC
IP Video Input 4-ch(only IP up to 12ch)
Supported Analog Camera Types Support AHD input: 8MP@15fps (channel1-channel2)
5MP@20fps
4MP@30fps
3MP@30fps(channel1 - channel2)
1080P@30fps
720P@60fps
Support TVI input: 8MP@15fps(channel1-channel2)
5MP@20fps
4MP@30fps
3MP@20fps (channel1 - channel2)
1080P@30fps
720P@60fps
Support CVI input: 8MP@15fps(channel1-channel2)
4MP@30fps
1080P@30fps
720P@60fps
Support CVBS input
Audio Input 1-ch, RCA
Two-way Audio 1-ch, RCA
Channel Associated Audio 1-ch,RCA
Network
Incoming Bandwidth 40Mbps
Outgoing Bandwidth 64Mbps
Remote Users 128
Protocols TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE
Video/Audio Output
CVBS Output 1-ch, BNC
VGA Output 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
HDMI Output 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz,
1024x768/60Hz
Recording Resolution 8MP Lite/5MP Lite/4MP Lite
/3MP/1080P/960P/720P
/960H/4CIF/CIF
Audio Output 1-ch, RCA
Synchronous Playback 8-ch
Decoding
Decoding format H.265/H.264
Live View/ Playback 12MP/8MP/5MP/4MP
/3MP/1080P/960P/720P
/960H/4CIF/CIF/QCIF
Capability 1 x 4K@30,
1 x 6MP@30,
1 x 5MP@30,
2 x 4MP@30,
2 x 3MP@30,
3 x 3MP@25,
4 x 1080p@30,
8 x 720p@30,
Encoding
Frame Rate Main stream:
8MP Lite@8fps(channel1-channel2?
5MPLite@12fps
4MP Lite@15fps
3MP@15fps(channel1 - channel2)
2MP@15fps
720P@30fps
Sub stream:
D1@30fps(Max)
Hard Disk
SATA 2 SATA interfaces
Capacity Up to 10TB for each HDD
External Interface
Network Interface 1RJ45 10M/100M self-adaptive Ethernet Interface
USB Interface Rear panel?1 x USB2.0,Front panel?1xUSB2.0
Serial Interface 1 x RS485
Alarm In -
Alarm Out -
General
Power Supply 12V DC
Power Consumption: ? 8 W( without HDD )
Working Environment -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ? 90% RH(non-condensing)
Dimensions(W×D×H) 380mm ×315mm× 49mm (15" × 12.4"×1.9")
Weight ( without HDD ) <=1.9 Kg ( 4.19lb )

Take TVI-DVR-2208 for example
