Data Sheet

Code du produit:

XHD870-5MP

Résumé:

5MP, up to 2560x1936@20fps, 4-in-1: HDTVI/CVI/AHD/CVBS, D-WDR, Day&Night (ICR), AWB, AGC, OSD/UTC, IR up to 50ft(15m), DC12V

  • 5MP, jusqu'à 2560x1936 @ 20fps
  • 4-en-1: HDTVI/CVI/AHD/CVBS
  • D-WDR, jour et nuit (ICR)
  • AWB, AGC
  • OSD/UTC
  • IR jusqu'à 50ft (15m)
  • DC12V
Camera
Image Sensor 5 Mega pixels CMOS
Chipset 5MP Sensor + FH8538M
Effective Pixels 2560(H) x 1936(V)
Lowest illumination 0.02Lux@(F1.2, AGC ON), 0Lux with IR
Electronic Shutter Auto, 1/50s ~ 1/60,000s
Video System PAL/NTSC
Video Fram Rate AHD/TVI 20fps@2560x1936P
CVI 30fps@2560x1440P, adjustable
Video Output 1 channel, HDCVI / HDTVI / AHD / CVBS optional
Video Switch 2 bits switch
Smart IR Control Support
Day/Night Auto(ICR) / Color / B/W
WDR D-WDR
OSD Menu Support, coaxial cable control via DVR directly (UTC)
Other Function AWB, AGC
Lens 3.7mm Pinhole Lens
General
Power Supply DC12V +/-10%
Power Consumption
Working Environment -30°C ~ +60°C / Less than 95%RH
IR Distance 50ft (15m)
Transmission Distance Over 300m via 75-3 coaxial cable
