Data Sheet

Code du produit:

DS-K1T502DBWX-C

Résumé:

Manage access control and intercom functions in one device, IP65 & IK09 protections, as well as increased stability with zinc alloy materials, Supports multiple authentication methods, Remote control via the Hik-Connect mobile app, Connects to external access controller via Wiegand protocol, Video intercom via SIP protocol. Supported SIP server: Brekeke, miniSipServer, and FreePBX, RS-485 communication for connecting external card reader and calling elevator, Supports AP mode, Press calling button to call one of the following objects: management center, indoor station, specified indoor station, or Hik-Connect App, Supports up to 256 GB SD card memory,

  • Manage access control and intercom functions in one device
  • IP65 & IK09 protections, as well as increased stability with zinc alloy materials
  • Supports multiple authentication methods
  • Remote control via the Hik-Connect mobile app
  • Connects to external access controller via Wiegand protocol
  • Video intercom via SIP protocol. Supported SIP server: Brekeke, miniSipServer, and FreePBX
  • RS-485 communication for connecting external card reader and calling elevator
  • Supports AP mode
  • Press calling button to call one of the following objects: management center, indoor station, specified indoor station, or Hik-Connect App
  • Supports up to 256 GB SD card memory
  • System
  • Operating SystemLinux
  • Video
  • Lens1
  • Video Compression StandardH.264 and H.265
  • Resolution2 MP
  • FOVHFOV = 110°; VFOV = 81°; DFOV = 122°
  • Video StandardPAL (Default) and NTSC
  • Network
  • Wired Network10 M/100 M self-adaptive
  • Wi-FiSupport
  • Interface
  • Network Interface1
  • Lock Control1
  • Exit Button1
  • Door Contact Input1
  • Alarm Input1
  • Alarm Output1
  • TAMPER1
  • RS-4851
  • Wiegand1 (Input and output)
  • SD Card Slot1
  • Capacity
  • Card Capacity100,000
  • Event Capacity300,000
  • Authentication
  • Card TypeM1 card;DESfire card
  • Card Reading Distance0 ~ 3 cm
  • Function
  • Two-Way AudioSupport
  • Video IntercomSupport
  • Hik-ConnectSupport
  • General
  • Power Supply1 A (12 VDC to 24 VDC)
  • Power Consumption</=12 W
  • Working Temperature-40 C ~ +70 C (-40 °F ~ +158 °F)
  • Protective LevelIK09, IP65
  • LanguageArabic, English, French, Indonesian, Italian, Portuguese (Brazil), Russian, Spanish (Europe), Thai, Ukrainian, Vietnamese, German, Polish, Hungarian, Czech, Romanian, Bulgarian, Croatian, Serbian, Greek, Slovak, Portuguese, and Dutch
