Data Sheet

Product Code:



up to 12MP,8CH IP up to 2MP (1920x1080), 80Mbps, 1x HDMI, 1x VGA, H.265+/H.265, 6 × 1080p@30 fps, SMD+, Audio 1in/1out, 1x RJ45 10/100M, 1x SATA up to 16TB/ea, 2xUSB2.0

· Smart H.265+/H.265/Smart H.264+/H.264 decoding format
· Max. decoding capability: 6 × 1080p@30 fps. Supports adaptive
· AI by camera: perimeter protection,and SMD Plus
· Connected to the third-party network cameras
· Security baseline 2.1
Technical Specification
Main Processor Industrial-grade embedded processor
Operating System Embedded Linux
Operating Interface Web; Local GUI
AI Perimeter protection; SMD Plus
Perimeter Performance of AI by Camera (Number of Channels) 4
SMD Plus by Camera 4-channel SMD Plus (AI by camera), secondary filtering for human and motor vehicle SMD Plus, reducing false alarms caused by leaves, rain and lighting condition change
Access Channel 8 channels
Network Bandwidth Access: 80 Mbps; Storage: 80 Mbps; Forward: 60 Mbps
Resolution 12MP; 8MP; 5MP; 4MP; 3MP; 2MP; 720p; D1
Decoding Capability 1-channel 12MP@30 fps; 1-channel 8MP@30 fps; 2-channel 5MP@30 fps; 3-channel 4MP@30 fps; 6-channel 1080p@30 fps
Video Output 1 × VGA, 1 × HDMI (simultaneous)
Multi-screen Display 1, 4, 8, 9 views
Third-party Camera Access Onvif
Video Compression Smart H.265; H.265; Smart H.264; H.264
Audio Compression PCM; G711A; G711U; G726
Network Protocol HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); P2P
Mobile Phone Access Android; iOS
Interoperability ONVIF (profile T/S/G); CGI; SDK
Browser Chrome; IE 9 or later; Firefox
