NVMS - Network Video Management System
NVMS - Network Video Management System
Data Sheet
Product Code:
Product Code:
NVMS6100
Summary:Inter1037U, 4GB RAM, Linux, up to 16 devices, Central live view, playback, backup, adjust settings, GPU hardware decoding, Max 36ch D1, 18ch 720P, 9ch 1080P live view, HDMI/VGA output, USB
- Max management 16 pcs NVSS or DVR/NVR, each device up to 256 channels
- Max 64 display group preview setup, Support GPU hardware decode function
- Up to 9ch 5M / 4M / 3M / 1080P @ 16ch, 720P @ 32ch D1 realtime preview
- Up to 9ch 5M / 4M / 3M / 1080P @ 16ch, 720P relatime remote playback
- Support remote playback and download
- Support Virtual Matrix/TV WALL management via VMDS device
- Support device alarm linkage and log seach function
- With 64G VMS mSata card, support remote help function with Teamviewer
System | |
Main Processor | Intel 1037U |
RAM | 4GB |
Operating System | 64-bit Linux |
Case | Mini case |
Control Mode | Mouse |
Supported List | Hikvision, Dahua, Xiongmai, including DVR / NVR /HCVR / HDTVR |
Display | |
Video Output | 1ch HDMI,1ch VGA |
Display Split | 1/4/6/9/13/16/20/25/36 |
Resolution | Self adapted, supports 1920x1080, 1600x1050, 1280x1024, 1024x768 |
Tour Display | 64 Display groups with sequence supported |
Compression | H.264 |
Decoding | Max 36ch D1, 18ch 720P, 9ch 1080P |
Remote-Playback Function | Simultaneous play, single frame, Icon Search, Record mode filter, Backup, Grab |
Max Connections | Up to 16 devices supported |
Display | |
USB | 4x USB ports |
Ethernet | 1x 1000Mbps RJ45 ports |
Power Supply | 12V, 5A |
Power Consumption | Max. 60W |
