Data Sheet

Product Code:

GX-K1802M

Summary:

Support 13.56Mhz Mifare Card, supports Wiegand (W26/W34) protocols, 8 Bit Processor, Reader Status LED Indicator, Single Tone Audible Buzzer, Weatherproof, IP65

  • Mifare Card Wiegand Reader
  • Support 13.56Mhz Mifare Card
  • supports Wiegand (W26/W34) protocols
  • 8 Bit Processor
  • Reader Status LED Indicator
  • Single Tone Audible Buzzer
  • Weatherproof
  • IP65
  • Working Temperature -4°F to 149°F(-20°C to +65°C)
Power Supply 12V DC
Power Consumption
Processor 8-bit
Reading Frequency 13.56MHz
Reading Range
Radio Frequency Standard ISO 14443-A
Audio Alert Beeper
LED Indicator Power Indicator, Status Indicator
Working Temperature -20°C to +65°C (-4°F to 149°F)
Working Humidity 10% to 90% (Non Condensing)
Dimensions 115.9mm x 43.3mm x 17mm (4.56" x 1.70" x 0.67")
Protection Level IP65
Installing Method Wall Mounting with Screws; Do Not Support Gang Box
