MileSight Enterprise NVR with 16-CH License, 6 Disk Slots.2U
MileSight Enterprise NVR with 16-CH License, 6 Disk Slots.2U
Model: VE0601-A
Available in stock
Open here
* Integrate with Milesight network cameras, sensors and 3rd party network cameras
* Support up to 6*20TB storage and expandable storage capacity
* Pre-loaded with Milesight VMS Server & Client
* Central Management for single and multiple sites
* N+M Failover ensures data security
* Windows-based operating system
* 1*PCI-E4 slot;
* 2*SO-DIMM DDR4 2666 Slot (2*4GB /2*8GB Pre-installed)
* 1*HDMI Port+1*DP Port(Support independent and synchronous display)
* 1*Power Connector(ATX_PWR 24pin) + 1*Power Connector (CPU_PWR 4pin) +1*CPU Fan+1*COM Connector (9pin) +1*Front Panel Connector
* 1* HD Audio Connector
* Front panel: 2*USB 2.0 +Rear panel: 2*USB 2.0, 2*USB 3.0
* AC 100-240V, 50-60Hz
Couldn't load pickup availability
- Integrate with Milesight network cameras, sensors and 3rd party network cameras
- Support up to 6*20TB storage and expandable storage capacity
- Pre-loaded with Milesight VMS Server & Client
- Central Management for single and multiple sites
- N+M Failover ensures data security
- Windows-based operating system
- 1*PCI-E4 slot;
- 2*SO-DIMM DDR4 2666 Slot (2*4GB /2*8GB Pre-installed)
- 1*HDMI Port+1*DP Port(Support independent and synchronous display)
- 1*Power Connector(ATX_PWR 24pin) + 1*Power Connector (CPU_PWR 4pin) +1*CPU Fan+1*COM Connector (9pin) +1*Front Panel Connector
- 1* HD Audio Connector
- Front panel: 2*USB 2.0 +Rear panel: 2*USB 2.0, 2*USB 3.0
- AC 100-240V, 50-60Hz
| Model | VE0601-A |
|---|---|
| Device | |
| Appearance | Appearance |
| Devices | |
| Included Camera Access License | 16 |
| Recording | |
| Recording Schedule | 16 |
| Decoding | |
| Video Format | MJPEG, H.264, H.265 |
| Decoding Resolution | Up to 12 MP |
| Decoding Capability* | Display with 1080P Monitor D1(704*576)@25fps=36ch, 2MP(1920*1080)@25fps=25ch 5MP(2592*1944)@25fps=11ch,12MP(4000*3000)@25fps=5ch |
| Event & Alarm | |
| Event and Alarm Rules | 1000 |
| Users & Roles | |
| Concurrent Accesses via Clients, App Clients | 300 |
| Users&Roles | 1000/100 |
| System | |
| Main Processor | 2.0 GHz Intel Celeron Series |
| Memory | 2*8GB DDR4 |
| Network Interface | 4*2.5 GbE RJ-45 ports |
| Operating System | Microsoft Windows 10 IoT Enterprise 64bit |
| GPU Options | Integrated GPU |
| Auto Power On | Support |
| Auxiliary Interface | |
| HDD Drives(Video Data) | 6*SATA (3.5" or 2.5") |
| SSD Drive (Operating System) | M.2 SSD(1*256 GB Pre-installed) |
| RAM | 2*SO-DIMM DDR4 2666 Slot (2*4GB /2*8GB Pre-installed) Support Up to 16GB, Support Dual-Channel Mode |
| Capacity | Up to 20TB capacity for each disk |
| RAID | NA |
| Recording Storage Capacity | Up to 6*20TB raw |
| LAN | 4*2.5Gbps LAN |
| PCI-E | 1*PCI-E4 slot |
| Display | 1*HDMI Port1*DP Port, Support independent and synchronous display |
| Audio | 1* HD Audio Connector |
| USB Interface | Front panel: 2*USB 2.0, Rear panel: 2*USB 2.0, 2*USB 3.0 |
| Power Supply | AC 100-240V, 50-60Hz |
| General | |
| Consumption | ≤30W (without HDD) |
| Working Conditions | Temperature:0°C to 35°C (32°F to 95°F) / Humidity 10% to 90% RH |
