MileSight Enterprise NVR with 16-CH License, 2 Disk Slots.1U
MileSight Enterprise NVR with 16-CH License, 2 Disk Slots.1U
Model: VE0201-A
Regular price
$1,749.60
Sale price
$1,749.60
Regular price
Available in stock
Open here
Couldn't load pickup availability
- Integrate with Milesight network cameras, sensors and 3rd party network cameras
- Support expandable disk capacity of 1*20TB or 2*20TB
- Pre-loaded with Milesight VMS Server & Client
- N+M Failover ensures data security
- Windows-based operating system
- 2*HDMI Port+1*DP Port(Support independent and synchronous display)
- Rear panel: 2*USB 2.0, 2*USB 3.0, 1*USB-C Port
- AC 100-240V, 50-60Hz, DC 12V
| VE0100-A | VE0201-A |
|---|---|
| Devices | |
| Appearance | Appearance |
| 8 | 16 |
| Recording | |
| 8 | 16 |
| Decoding | |
| MJPEG, H.264, H.265 | MJPEG, H.264, H.265 |
| Decoding Resolution | |
| Up to 12 MP | Up to 12 MP |
| Decoding Capability | |
| Display with 1080P Monitor 12MP(4000*3000)@20fps=6ch 8MP(3840*2160)@30fps=6ch 2MP(1920*1080)@30fps=8ch | Display with 1080P Monitor 12MP(4000*3000)@20fps=6ch 8MP(3840*2160)@30fps=6ch 2MP(1920*1080)@30fps=16ch |
| Event & Alarm | |
| 1000 | 1000 |
| Users & Roles | |
| 300 | 300 |
| Users | |
| 1000 | 1000 |
| Roles | |
| 100 | 100 |
| System | |
| Intel 2.0 GHz Celeron Series | Intel 2.0 GHz Celeron Series |
| Memory | |
| 2*4GB DDR4 | 2*4GB DDR4 |
| Network Interface | |
| 2*1000Mbps RJ-45 Ports | 2*1000Mbps RJ-45 Ports |
| Operating System | |
| Microsoft Windows 10 IoT Enterprise 64bit | Microsoft Windows 10 IoT Enterprise 64bit |
| GPU Options | |
| Integrated GPU | Integrated GPU |
| Auto Power On | |
| Support | Support |
| Auxiliary Interface | |
| 1*SATA (3.5" or 2.5") | 2*SATA (3.5" or 2.5") |
| SSD Drive (Operating System) | |
| M.2 SSD(1*256 GB Pre-installed) | M.2 SSD(1*256 GB Pre-installed) |
| RAM | |
| 2* DDR4 2666 Slot(2*4GB Pre-installed) Support Up to 16GB Support Dual-Channel Mode | 2* DDR4 2666 Slot(2*4GB Pre-installed) Support Up to 16GB Support Dual-Channel Mode |
| Capacity | |
| Up to 20TB capacity for each disk | Up to 20TB capacity for each disk |
| Recording Storage Capacity | |
| Up to 1*20TB raw | Up to 2*20TB raw |
| LAN | |
| 2*1000Mbps LAN | 2*1000Mbps LAN |
| Display | |
| 2*HDMI Port, 1*DP Port Support independent and synchronous display | 2*HDMI Port, 1*DP Port Support independent and synchronous display |
| Audio | |
| 1*BNC In, 1*BNC Out | 1*BNC In, 1*BNC Out |
| USB Interface | |
| Rear panel: 2*USB 2.0, 2*USB 3.0, 1*USB-C Port | Rear panel: 2*USB 2.0, 2*USB 3.0, 1*USB-C Port |
| Power Supply | |
| AC 100-240V, 50-60Hz, DC 12V | AC 100-240V, 50-60Hz, DC 12V |
| General | |
| ≤30W(without HDD) | ≤30W(without HDD) |
| Working Condition | |
| Temperature: 0°C to 35°C (32°F to 95°F), Humidity: 10% to 90% RH | Temperature: 0°C to 35°C (32°F to 95°F), Humidity: 10% to 90% RH |
