MileSight Enterprise NVR with 8-CH License, 1 Disk Slots.1U
MileSight Enterprise NVR with 8-CH License, 1 Disk Slots.1U
Model: VE0100-A
Regular price
$1,614.60
Sale price
$1,614.60
Regular price
Available in stock
Open here
* Integrate with Milesight network cameras, sensors and 3rd party network cameras
* Support expandable disk capacity of 1*20TB or 2*20TB
* Pre-loaded with Milesight VMS Server & Client
* N+M Failover ensures data security
* Windows-based operating system
* 2*HDMI Port+1*DP Port(Support independent and synchronous display)
* Rear panel: 2*USB 2.0, 2*USB 3.0, 1*USB-C Port
* AC 100-240V, 50-60Hz, DC 12V
Couldn't load pickup availability
- Integrate with Milesight network cameras, sensors and 3rd party network cameras
- Support expandable disk capacity of 1*20TB or 2*20TB
- Pre-loaded with Milesight VMS Server & Client
- N+M Failover ensures data security
- Windows-based operating system
- 2*HDMI Port+1*DP Port(Support independent and synchronous display)
- Rear panel: 2*USB 2.0, 2*USB 3.0, 1*USB-C Port
- AC 100-240V, 50-60Hz, DC 12V
| Enterprise NVR 1U Series | |
|---|---|
| Model | VE0100-A |
| Devices | |
| Appearance | Appearance |
| Included Camera Access License | 8 |
| Recording | |
| Recording Schedule | 8 |
| Decoding | |
| Video Format | MJPEG, H.264, H.265 |
| Decoding Resolution | Up to 12 MP |
| Decoding Capability | Display with 1080P Monitor 12MP(4000*3000)@20fps=6ch 8MP(3840*2160)@30fps=6ch 2MP(1920*1080)@30fps=8ch |
| Event & Alarm | |
| Event and Alarm Rules | 1000 |
| Users & Roles | |
| Concurrent Accesses via Clients, App Clients | 300 |
| Users | 1000 |
| Roles | 100 |
| System | |
| Main Processor | Intel 2.0 GHz Celeron Series |
| Memory | 2*4GB DDR4 |
| Network Interface | 2*1000Mbps RJ-45 Ports |
| Operating System | Microsoft Windows 10 IoT Enterprise 64bit |
| GPU Options | Integrated GPU |
| Auto Power On | Support |
| Auxiliary Interface | |
| HDD Drives (Video Data) | 1*SATA (3.5" or 2.5") |
| SSD Drive (Operating System) | M.2 SSD(1*256 GB Pre-installed) |
| RAM | 2* DDR4 2666 Slot(2*4GB Pre-installed) Support Up to 16GB Support Dual-Channel Mode |
| Capacity | Up to 20TB capacity for each disk |
| Recording Storage Capacity | Up to 1*20TB raw |
| LAN | 2*1000Mbps LAN |
| Display | 2*HDMI Port, 1*DP Port Support independent and synchronous display |
| Audio | 1*BNC In, 1*BNC Out |
| USB Interface | Rear panel: 2*USB 2.0, 2*USB 3.0, 1*USB-C Port |
| Power Supply | AC 100-240V, 50-60Hz, DC 12V |
| General | |
| Consumption | ≤30W(without HDD) |
| Working Condition | Temperature: 0°C to 35°C (32°F to 95°F), Humidity: 10% to 90% RH |
