Camera
Image Sensor	1/3"Sensor
Signal System	NTSC / PAL(Euro Version)
Effective Pixels	1920(H)x1080(V)
Min. Illumination	0.014Lux @ (AGC ON),0 Lux with IR
Shutter Speed	NTSC: 1/30 ~ 1/50,000 PAL: 1/25 ~ 1/50,000
Lens	2.8-12mm
Day & Night	ICR
Synchronization	Internal synchronization
Video Frame Rate	NTSC:1080p@30fps/PAL:1080p@25fps
HD Video Output	1 Analog HD output
Video Output	1 Vp-p composite output (75 ohm/BNC)
S/N Ratio	More than 52dB
Menu
Scene	Indoor, Outdoor, Indoor1, LOW-LIGHT
Camera ID	On / off (15 characters, position programmable)
AGC	Support
D / N Mode	Color / BW / EXT
White Balance	ATW, AWC-SET, Indoor, Outdoor, Manual
D/N Mode	Color/BW/SMART IR
Privacy Mask	On/Off,maximum 8 zones
Motion Detection	On / Off, maximum 4 zones
BLC	Support
Anti-flicker	On / off
Language	English, Japanese, CHN1, CHN2, Korean, German, French, Italian,Spanish,Polish, Russian, Portuguese, Dutch, Turkish, Hebrew and Arabic
Functions	Eclipse, Digital noise reduction, Digital zoom(62x), Slow shutter, Mirror, Defog, Defect pixel correction, SMART D-ZOOM
General
Working Temperature /Humidity	-20 °C - 60 °C (-4°F - 140°F)
	Humidity 90% or less (non-condensing)
Power Supply	12V DC,24V AC
Power Consumption	Max.10W
Weather Proof Ratings	IP66
IR Range	Up to 165ft(50m)
Communication	Up the coax(need UTC controller) ; Protocol: Pelco-C(Coaxitron)
Dimension(without junction box)	Dia.11.8" x 4.0"x 4.2" ( 300.8 x 100.8 x 107.6mm)
Weight(without junction box)	1.5lb(700g)
