| Video/Audio Input |
| Video/Audio Input |
H.265+/H.265/H.264 Zip+/H.264 |
| Video Input |
4-CH
BNC interface (1.0 Vp-p, 75 ?), supporting coaxition
|
| Supported HDTVI input |
5 MP, 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720 p25 |
| Supported AHD input |
1080p25, 1080p30, 720p25, 720p30 |
| CVBS input |
Support |
| IP Video Input |
4-ch, Up to 6 MP resolution, Supports H.265+/H.265/H.264+/H.264 IP cameras |
| Audio compression |
G.711u |
| Audio input |
4-ch, RCA (2.0 Vp-p, 1 k?) |
| Video/Audio Output |
| HDMI/ VGA output |
1 -ch , 19 20 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60 Hz |
| Encoding resolution |
5 MP/4 MP/3MP/1080p/720p/WD1/4CIF/VGA/CIF |
| CVBS output |
1-ch, BNC (1.0 Vp-p, 75 ?), resolution: PAL: 704×576, NTSC: 704×480 |
| Frame rate |
Main stream: 5MP@12fps/4 MP@15fps/3 MP@18fps;1080p/720p/WD1/@25fps(P)/30fps(N)
Sub-stream: WD1/4CIF/CIF@25fps (P)/30 fps (N)
|
| Video bit rate |
32 Kbps -10 Mbps |
| Audio output |
1-ch, RCA (Linear, 1 k?) |
| Audio bit rate |
64 Kbps |
| Dual- stream |
Support |
| Stream type |
Video, Video & Audio |
| Synchronous playback |
4ch |
| Network |
| Remote connections |
128 |
| Network protocols |
TCP/IP, PPPoE, DHCP, PT Cloud, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF |
| Hard Disk |
| SATA |
1 SATA |
| Capacity |
Up to 8TB capacity for each disk |
| External Interface |
| Network Interface |
1, RJ45 10M / 100Mself-adapt ive Ethernet interface |
| Serial Interface |
1; RS-485 serial interface, half-duplex |
| USB Port |
2 × USB2.0 |
| Alarm In/Out |
4/1 |
| General |
| Power Supply |
DC 12V |
| Consumption |
? 10W |
| Working Temperature |
-10 °C ~ +55 °C(14°F - 131°F) |
| Working Humidity |
10% - 90% |
| Chassis |
1U compact case |
|
