8 CHANNEL 4K DEEP LEARNING NETWORK VIDEO RECORDER
8 CHANNEL 4K DEEP LEARNING NETWORK VIDEO RECORDER
Model: SVDN8608D-P8
Regular price
$810.55
Sale price
$810.55
Regular price
Available in stock
🖨️ Print as PDF
×
Send a copy to email:
By entering your email, you agree that it will be seen by store and may contact you.
Open here
8 Channel 4K Deep Learning NVR
No HDD included
Support Live View, Storage, and Playback up to 12.3MP IP Camera
4ch Deep Learning Detection
80MB Input Bandwidth
8 Built-in PoE
4K (3840x2160) HDMI, VGA, CVBS Video Output
2 SATA up to 12TB HDD
4 POS via TCP/IP
Support 6MP / 12.3MP Fisheye
Support H.264/H.264 Zip+, H.265 Ready
Couldn't load pickup availability
- Quad-core 8 Channel Network Video Recorder
- Support Live View, Storage, and Playback up to 12.3MP IP Camera
- 4ch Deep Learning Detection
- 80MB Input Bandwidth
- 8 Built-in PoE
- 4K (3840x2160) HDMI, VGA, CVBS Video Output
- 2 SATA up to 12TB HDD
- 4 POS via TCP/IP
- Support 6MP / 12.3MP Fisheye
- Support H.264/H.264 Zip+, H.265 Ready
| Video/Audio Input | |
| IP Video Input | 8-CH, Up to 12MP Resolution |
| Two-Way Audio Input | 1-CH, RCA (2.0 Vp-p, 1k?) |
| Network | |
| Incoming Bandwidth | 80Mbps |
| Outgoing Bandwidth | 256Mbps |
| Remote Connection | 128 |
| Video/Audio Output | |
| Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| HDMI Output | 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 ×1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA Output | 1-ch, resolution: 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| CVBS Output | 1-ch |
| Audio Output | 1-CH, RCA (Linear, 1k?) |
| Decoding | |
| Live View/ Playback Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback | 8-CH |
| Capability | 2-ch @ 4K, or 8-ch @1080p |
| Hard Disk | |
| SATA | 2 SATA Interfaces for 2 HDDs |
| Capacity | Up to 8TB for Each Disk |
| External Interface | |
| Network Interface | 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces |
| USB Interface | Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 |
| Alarm In/Out | 4/1 |
| PoE | |
| Interface | 8 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Max. Power | ?120W |
| Supported Standard | IEEE 802.3 af/at |
| General | |
| Power Supply | 100~240V AC |
| Consumption | ?15W |
| Working Temperature | +14ºF ~ +131 ºF(-10ºC ~ +55ºC) |
| Working Humidity | 10% - 90% |
| Casing | 19-Inch Rack-Mounted 1U Casing |
| Dimension | 380 × 315× 52 mm (15" × 12.4" × 2.0") |
| Weight | ?8.8lb (4Kg) |
