MileSight OpenVision Server Mini 16-Channel - SE0216-K/NX/A05
MileSight OpenVision Server Mini 16-Channel - SE0216-K/NX/A05
Model: SE0216-K/NX/A05
Regular price
$1,696.50
Sale price
$1,696.50
Regular price
Available in stock
Open here
MileSight OpenVision Server Mini supports up to 16 IP camera channels with an Intel quad-core processor, dual 2.5 GbE ports, Nx Witness integration and up to 8 TB of M.2 SSD storage in a fanless enclosure.
Couldn't load pickup availability
- Support for up to 16 camera channels
- Quad-core Intel processor up to 3.40 GHz with 4 GB LPDDR5
- Nx Witness server and Milesight plugin support; Nx channel licenses separate
- Two 2.5 Gbps Ethernet ports, HDMI outputs and local USB connectivity
- Dual M.2 SSD bays; up to 8 TB combined capacity
- Ubuntu Linux 24.04 LTS software platform
- PoE+ or DC 12 V power
- Fanless 135 × 140 × 40 mm housing; DIN rail, bracket or VESA installation
- Consumption: Typical: 6W (Without SSD, DC), 7W (Without SSD, POE) MAX: 16W (With SSD, DC), 18W (With SSD, POE)
- Working Temperature: -20°C to 60°C
- Working Humidity:10% to 90% RH (No freezing and no condensation)
- Dimension:135mm(W) X 140mm(D) X 40mm(H) (Without Mount)
- Weight:1.0 Kg Installation:DIN Rail Mount, VESA Mount, Bracket Mount
- Analytics Events: CCTV (Intrusion Detection/ Region Entrance/ Region Exit/ Advanced Motion Detection/ Line Crossing/ Loitering/ Object Left/Object Removed/ Object Counting/ Regional People Counting); LPR (Attribute Event/ Black List/ White List/ Visitor Event/ Speed Monitoring/ No Plates/ Reverse Driving); Object Detected Events (person and vehicle with attribute/ face)
| System | |
|---|---|
| Model | SE0216-K/Nx/A05 |
| Maximum channels | 16 IP cameras |
| Processor | Intel quad-core, up to 3.40 GHz |
| RAM | 4 GB LPDDR5 |
| Operating system | Ubuntu Linux 24.04 LTS |
| GPU | Integrated |
| Firmware storage | 32 GB eMMC (8-channel manufacturer datasheet) |
| Supported video input | 12 MP down to CIF |
| Video formats | H.265, H.264, MJPEG |
| Recording & storage | |
| Disk slots | 2 × M.2 SSD |
| Supported SSD capacity | Up to 4 TB per SSD |
| Total storage | Up to 8 TB |
| Recording bandwidth | Not specified in supplied catalog for 16-channel variant |
| Outgoing bandwidth | Not specified in supplied catalog for 16-channel variant |
| Hardware ports | |
| LAN | 2 × 2.5 Gbps RJ45 Gigabit Ethernet (2500 Mbps) |
| Ethernet power | PoE Powered Device (PD) on supported port |
| HDMI | 2 × HDMI, up to 4K / 60 Hz (8-channel datasheet) |
| Audio | 3.5 mm combo headphone/microphone port |
| USB | 3 × USB 3.0; 1 × USB 2.0 (supplied dealer catalog; verify model revision) |
| Alarms | Not separately specified for 16-channel configuration |
| Software & analytics | |
| Nx platform | Nx Witness server preconfigured; Nx channel licenses are not included |
| Milesight software | Milesight Nx plugin, remote management, two-way audio and recording |
| Interoperability | ONVIF cameras; Nx client/mobile/cloud integration |
| Edge analytics | Detection and metadata-driven events from compatible cameras |
| Analytics categories | Intrusion, region entrance/exit, motion/line crossing, loitering, abandoned/removed objects, people/vehicle counting, LPR events, attributes |
| Processing limits | Not specified in supplied catalog for 16-channel variant |
| Power & general | |
| Power input | DC 12 V ±15% or PoE+ (IEEE 802.3at) |
| Power consumption | Typical 6 W DC / 7 W PoE without SSD; maximum 16 W DC / 18 W PoE with SSD |
| Cooling | Fanless |
| Temperature | −20 °C to +60 °C |
| Humidity | 10–90% RH, non-condensing |
| Dimensions | 135 × 140 × 40 mm (without mount) |
| Weight | Approx. 1.0 kg |
| Installation | DIN rail, VESA, or bracket mounting |
| NDAA | Yes (supplied dealer catalog) |
| Warranty | 3 years (8-channel manufacturer datasheet) |
| Exact SKU & dealer catalog cross-check | |
| Galaxy order model | SE0216-K/NX/A05 |
| Dealer series | Openvision Series |
| Production status | MP |
| Catalog resolution | 12MP ~ CIF |
| Catalog frame rate / camera channels | Max. 16CH |
| P-Iris / CPU | Intel Quad Core @3.40 GHz Max |
| Lens / RAM | 4GB LPDDR5 |
| Aperture / Ethernet | 2*2500Mbps RJ45 Ethernet Port, support POE PD |
| Sensor / operating system | Linux Ubuntu 24.04 LTS |
| Field of view / graphics | Integrated GPU |
| WDR / SSD capacity | Max 8TB, up to 4TB per disk, SSD slot*2 |
| IR distance / compression | H.265, H.264, MJPEG |
| White-light / Network | 2*2500Mbps RJ45 Ethernet Port, support POE PD |
| Appearance / HDMI | 2* HDMI Port |
| Microphone / Audio | 1 x Headphone Jack with Microphone Input |
| Interface / USB | 3*USB 3.0, 1*USB 2.0 |
| Included accessories / Power | PoE+ (802.3at) / DC 12V±15% (5525 DC power plug) |
| NDAA | Yes |
