MileSight OpenVision Server
MileSight OpenVision Server
Model: SE0208-K/Nx
Regular price
$1,462.50
Sale price
$1,462.50
Regular price
Available in stock
Open here
*Consumption: Typical: 6W (Without SSD, DC), 7W (Without SSD, POE)
MAX: 16W (With SSD, DC), 18W (With SSD, POE)
*Working Temperature: -20°C to 60°C
*Working Humidity:10% to 90% RH (No freezing and no condensation)
*Dimension:135mm(W) X 140mm(D) X 40mm(H) (Without Mount)
*Weight:0.99 Kg
Installation: VESA Mount
Couldn't load pickup availability
- Analytics Events:
- CCTV (Intrusion Detection/ Region Entrance/ Region Exit/ Advanced Motion Detection/ Line Crossing/ Loitering/ Object Left/Object Removed/ Object Counting/ Regional People Counting);
- LPR (Attribute Event/ Black List/ White List/ Visitor Event/ Speed Monitoring/ No Plates/ Reverse Driving);
- Object Detected Events (person and vehicle with attribute/ face)
- Consumption: Typical: 6W (Without SSD, DC), 7W (Without SSD, POE)
- MAX: 16W (With SSD, DC), 18W (With SSD, POE)
- Working Temperature: -20°C to 60°C
- Working Humidity:10% to 90% RH (No freezing and no condensation)
- Dimension:135mm(W) X 140mm(D) X 40mm(H) (Without Mount)
- Weight:0.99 Kg
- Installation: VESA Mount
- Resolution: 12MP ~ CIF
- Inputs: Max. 8CH
- Main Processor: Intel Quad Core @3.40 GHz Max
- Memory: 4GB LPDDR5
- Network Interface: 1*2500Mbps RJ45 Ethernet Port, support POE PD
- Supported HDD: Max 8TB, up to 4TB per disk, SSD slot*2
- Compression: H.265, H.264, MJPEG
- Ethernet: 1*2500Mbps RJ45 Ethernet Port, support POE PD
- Display: 2* Micro HDMI Port
- Audio: 1 x Headphone Jack with Microphone Input
- USB Interface: 3*USB 3.0, 1*USB 2.0
- Power Supply: PoE+ (802.3at) / DC 12V±15% (5525 DC power plug)
| Series | Openvision Series |
|---|---|
| Product name | OpenVision Server |
| Main Model Name | SE0208-K/Nx |
| Order Model Name | SE0208-K/Nx |
| Model | SE0208-K/NX |
| System | |
| MainProcessor | IntelQuadCore@3.40GHzMax |
| Memory | 4GBLPDDR5 |
| FirmwareStorage | 32GBeMMC |
| OperatingSystem | LinuxUbuntu24.04LTS |
| GPUOptions | IntegratedGPU |
| TPM | fTPM |
| AutoPowerOn | Support |
| Storage | |
| SupportedSSD | Max8TB,upto4TBperdisk |
| SSDSlot | 2*M.2M-KeySSD |
| Network | |
| Protocol | IPv4,IPv6,TCP/IP,UDP/IP,RTP(UDP),RTP(TCP),RTSP,NTP,HTTP,DHCP(Client),ICMP,IGMP,ARP,DNS, HTTPS,ONVIF,NFS,SMB |
| Audio | |
| Compression | G.711/AAC/G.726 |
| AudioCommunication | 2-way |
| Performance | |
| VideoInputs | Max.8CH |
| VideoResolution | 12MP~CIF |
| NetworkBandwidth | Max.80MbpsRecording,Max.160MbpsOutgoing |
| VideoCompression | H.265,H.264,MJPEG |
| DecodingCapability | Serverdisabled: 4channelsof12MP@30fps;6channelsof8MP@30fps; 9channelsof4MP@30fps;16channelsof1080p@30fps; Serverenabled(LimitedMetadata*): 2channelsof4MP@30fps;4channelsof1080p@30fps; *LimitedMetadata:lessthan5objectspersecond |
| StorageMode | Continuous,Motion,Events,Objects,DualStream |
| Application | |
| NXWitnessServer | Support(IncludePlug-in) |
| NXWitnessClient | Support |
| ONVIFDevice | Support |
| Management | |
| WebManagement | Support |
| BasicEvent | AudioAlarm,NetworkDisconnected,IPAddressConflict SSDFull,SSDUninitialized,SSDError,NoSSD |
| Maintenance | FirmwareUpgrade,AutoReboot |
| Interface | |
| Ethernet | 1*2500MbpsRJ45EthernetPort,supportPOEPD |
| Display Audio | 2*MicroHDMIPort |
| 1xHeadphoneJackwithMicrophoneInput | |
| AlarmI/O | 4/2 |
| Indicatorlight | 2 |
| ResetButton | Yes |
| USBInterface | 3*USB3.0,1*USB2.0 |
| PowerSupply | PoE+(802.3at)/DC12V±15%(5525DCpowerplug) |
| General | |
| Consumption | Typical:6W(WithoutSSD,DC),7W(WithoutSSD,POE) MAX:16W(WithSSD,DC),18W(WithSSD,POE) |
| WorkingTemperature | -20°Cto60°C |
| WorkingHumidity | 10%to90%RH(Nofreezingandnocondensation) |
| Dimension | 135mm(W)X140mm(D)X40mm(H)(WithoutMount) |
| Installation | VESAMount |
| NetWeight | 0.99Kg |
| PackageWeight | 1.3Kg |
| Warranty | 3Years |
