MileSight OpenVision Server
MileSight OpenVision Server
Model: SE0201-K/Nx
Regular price
$2,025.00
Sale price
$2,025.00
Regular price
Available in stock
Open here
*Consumption: ≤30W (without HDD)
*Working Temperature: 0°C to 35°C (32°F to 95°F)
*Working Humidity:10% to 90% RH (no freezing and no condensation)
*Dimension:380mm(W) X 317.6mm(D) X 51.8mm(H)
*Weight:2.2 Kg
Couldn't load pickup availability
- Analytics Events:
- CCTV (Intrusion Detection/ Region Entrance/ Region Exit/ Advanced Motion Detection/ Line Crossing/ Loitering/ Object Left/Object Removed/ Object Counting/ Regional People Counting);
- LPR (Attribute Event/ Black List/ White List/ Visitor Event/ Speed Monitoring/ No Plates/ Reverse Driving);
- Object Detected Events (person and vehicle with attribute/ face)
- Consumption: ≤30W (without HDD)
- Working Temperature: 0°C to 35°C (32°F to 95°F)
- Working Humidity:10% to 90% RH (no freezing and no condensation)
- Dimension:380mm(W) X 317.6mm(D) X 51.8mm(H)
- Weight:2.2 Kg
- Resolution: 12MP ~ CIF
- Inputs: Max. 16CH
- Main Processor: Intel Celeron Series, 4C 4T @2.00 GHz
- Memory: 2*4GB DDR4
- Network Interface: 2*1000Mbps RJ-45 Ports
- Supported HDD: Up to 20TB per disk; SATA*2
- Compression: H.265, H.264, MJPEG
- Ethernet: 2*1000Mbps Ethernet Port
- Display: 2*HDMI Port, 1*DP Port
- Audio: 1*BNC In, 1*BNC Out
- USB Interface: Rear panel: 2*USB 2.0, 2*USB 3.0, 1*USB-C Port
- Power Supply: AC 100-240V, 50-60Hz, DC 12V
| Series | Openvision Series |
|---|---|
| Product name | OpenVision Server |
| Main Model Name | SE0201-K/Nx |
| Order Model Name | SE0201-K/Nx |
| Model | SE0201-K/Nx |
| Image | |
| Inputs | Max.16CH |
| Resolution | 12MP~CIF |
| System | |
| MainProcessor | IntelCeleronSeries,4C4T@2.00GHz |
| Memory | 2*4GBDDR4 |
| NetworkInterface | 2*1000MbpsRJ-45Ports |
| OperatingSystem | LinuxUbuntu22.04.5LTSDesktop |
| GPUOptions | IntegratedGPU |
| AutoPowerOn | Support |
| Record | |
| VideoCompression | H.265,H.264,MJPEG |
| RecordingBandwidth | Max.144Mbps |
| Resolution | 12MP~CIF |
| Mode | Continuous,Motion,Events,Objects,DualStream |
| EdgeAnalytics | AnalyticsEvents: CCTV(IntrusionDetection/RegionEntrance/RegionExit/AdvancedMotionDetection/LineCrossing/ Loitering/ObjectLeft/ObjectRemoved/ObjectCounting/RegionalPeopleCounting); LPR(AttributeEvent/BlackList/WhiteList/VisitorEvent/SpeedMonitoring/NoPlates/Reverse Driving); ObjectDetectedEvents(personandvehiclewithattribute/face) |
| EventAction | Bookmark,CameraOutput,CameraRecording,DoHTTP(S)Request,ExecutePTZPreset,PlaySound,etc. |
| Storage | |
| SupportedHDD | Upto20TBperdisk |
| HDDSlot | SATA*2 |
| Protocol | IPv4,IPv6,TCP/IP,UDP/IP,RTP(UDP),RTP(TCP),RTSP,NTP,HTTP,DHCP(Client),SMTP,ICMP,IGMP,ARP, DNS,DDNS,SNMP(Client),HTTPS,ONVIF |
| Audio | |
| Compression | G.711/AAC/G.722/G.726 |
| AudioCommunication | 2-way |
| Interface | |
| Ethernet | 2*1000MbpsEthernetPort |
| Display | 2*HDMIPort,1*DPPort Note:Displayportsareforsystemsetupanddiagnosticsonly.Theydonotsupportvideoplaybackor desktopdisplay. |
| Audio | 1*BNCIn,1*BNCOut |
| USBInterface | Rearpanel:2*USB2.0,2*USB3.0,1*USB-CPort |
| PowerSupply | AC100-240V,50-60Hz,DC12V |
| General | |
| Consumption | ≤30W(withoutHDD) |
| WorkingTemperature | 0°Cto35°C(32°Fto95°F) |
| WorkingHumidity | 10%to90%RH(nofreezingandnocondensation) |
| Dimension | 380mm(W)X317.6mm(D)X51.8mm(H) |
| Weight | 2.2Kg |
| Warranty | 3Years |
