Galaxy 64CH 32MP 8x SATA NVR
Galaxy 64CH 32MP 8x SATA NVR
Model: NR710-64S
Available in stock
Send a copy to email:
By entering your email, you agree that it will be seen by store and may contact you.
Open here
up to 32MP64CH IP up to 32MP (8192x3840), 384Mbps, 2x HDMI, 1x VGA, H.265+/H.265, 32-ch@1080p, People Counting, Audio 1in/2out, Alarm 16in/9out, 2x RJ45 10/100/1000M, 8x SATA up to 14TB/ea, 2xUSB2.0, 2xUSB3.0, 1x eSATA, 1x RS-232, 1x RS-485
Couldn't load pickup availability
- H.265+/H.265/H.264+/H.264 video formats
- Intelligent analytics based on deep learning algorithm
- Up to 4-ch perimeter protection
- Up to 4-ch facial recognition for video stream
- Up to 8-ch facial recognition for face picture
- Up to 64-ch IP camera inputs
- Up to 32-ch 1080p decoding capability
|
Intelligent Analytics |
|
|
AI by NVR |
Facial recognition, perimeter protection, motion detection 2.0 |
|
AI by Camera |
Facial recognition, perimeter protection, video structuralization, throwing objects from building, motion detection 2.0, ANPR, people counting, VCA |
|
Engine |
1, engine mode is adjustable |
|
Facial Recognition |
|
|
Facial Detection and Analytics |
Face picture comparison, human face capture, face picture search |
|
Face Picture Library |
Up to 16 face picture libraries, with up to 50,000 face pictures in total (each picture </= 512 KB, total capacity </= 1 GB) |
|
Face Picture Comparison (Captured from Camera) |
8-ch |
|
Facial Detection and Analytics Performance |
4-ch human face capture (HD network camera, up to 8 MP, H.264/H.265) |
|
Motion Detection 2.0 |
|
|
By NVR |
All channels for Hikvision cameras |
|
By Camera |
All channels |
|
Perimeter Protection |
|
|
By NVR |
4-ch, 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm; Up to 12 rules in total |
|
By Camera |
All channels |
|
ANPR |
|
|
By Camera |
All channels |
|
Vehicle Attributes |
Plate number, license plate color, license plate type |
|
Plate Attributes |
Vehicle brand, vehicle color, vehicle type |
|
Video and Audio |
|
|
IP Video Input |
64-ch |
|
Incoming Bandwidth |
384 Mbps |
|
Outgoing Bandwidth |
256 Mbps |
|
HDMI 1 Output |
4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
|
HDMI 2 Output |
4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
|
VGA 1 Output |
1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
|
VGA 2 Output |
1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
|
Video Output Mode |
HDMI1/VGA1 simultaneous output, HDMI2/VGA2 simultaneous output,HDMI1/HDMI2 independent output |
|
CVBS Output |
1-ch, BNC (1.0 Vp-p, 75 Ohm), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
|
Audio Output |
2-ch, RCA (Linear, 1 K Ohm) |
|
Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 K Ohm) |
|
Decoding |
|
|
Decoding Format |
H.265+/H.265/H.264+/H.264 |
|
Recording Resolution |
32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF *: The NVR supports up to 4-ch 32 MP/24 MP IP video inputs. |
|
Synchronous Playback |
16-ch |
|
Live View Window Division |
1/2/4/6/8/9/16/25/32/36/64 |
|
Aux Port Window Division |
1/2/4/6/8/9/16/25/32/36 |
|
Decoding Capability |
Enable AI by NVR: 20-ch@1080p (30 fps) Disable AI by NVR: 32-ch@1080p (30 fps) |
|
Dual-Stream Recording |
Support |
|
Stream Type |
Video, Video & Audio |
|
Audio Compression |
G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2/PCM |
|
Network |
|
|
Network Interface |
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
|
Remote Connection |
128 |
|
Network Protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
|
API |
ONVIF (profile S/G); SDK; ISAPI |
|
Compatible Browser |
IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version |
|
RAID |
|
|
RAID Type |
RAID0, RAID1, RAID5, RAID6, RAID10 Support global hot spare |
|
Auxiliary Interface |
|
|
Serial Interface |
1 RS-485 (full-duplex), 1 RS-232 |
|
SATA |
8 SATA interfaces |
|
Capacity |
Up to 14 TB capacity for each disk |
|
eSATA |
1 eSATA interface |
|
Alarm In/Out |
16/9 |
|
USB Interface |
Front panel: 2 × USB 2.0; Rear panel: 2 × USB 3.0 |
|
General |
|
|
GUI Language |
English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian, Hebrew |
|
Power Supply |
100 to 240 VAC, 50 to 60 Hz |
|
Consumption |
</= 30 W (without HDD) |
|
Working Temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
|
Working Humidity |
10% to 90% |
|
Chassis |
2U chassis |
|
Dimension (W × D × H) |
440 × 457 × 94 mm ( 17.4"× 18.0" × 3.7") |
|
Weight |
</= 7.1 kg (without HDD, 15.7 lb.) |
|
Certification |
|
|
Obtained Certification |
CE, CB, REACH, WEEE, UKCA, LOA |
|
CE |
EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4 |
