Camera

Image Sensor

1/2.7" Progressive Scan CMOS

Min. Illumination

0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR

Shutter Speed

1/3 s to 1/100,000 s

Slow Shutter

Yes

Day & Night

ICR Cut

WDR

120 dB

Angle Adjustment

Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

Lens

Lens Type

1.68 mm

Focus

Fixed

Aperture

F2.0

FOV

Horizontal: 180°, vertical: 101°, diagonal: 180°

Lens Mount

M12

Illuminator

IR Range

20 m

Wavelength

850 nm

Smart Supplement Light

Yes

Video

Max. Resolution

2688 × 1520

Main Stream

50Hz: 25fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720)

60Hz: 24fps (2688 × 1520), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)

Sub-Stream

50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)

60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)

Video Compression

Main stream: H.265+/H.265/H.264+/H.264

Sub-stream: H.265/H.264 /MJPEG

H.264 Type

Main Profile/High Profile

H.265 Type

Main Profile

Video Bit Rate

32 Kbps to 16 Mbps

Bit Rate Control

CBR/VBR

Stream Type

Main stream, sub-stream

Scalable Video Coding (SVC)

H.264 and H.265

Smart Feature-Set

Smart Event

Line crossing detection, intrusion detection, unattended baggage detection, object

removal detection, face detection, scene change detection

Linkage Method

Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture.

Trigger recording: memory card, network storage, pre-record and post-record. Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email. Trigger notification:

HTTP, ISAPI, alarm output, Email

Region of Interest (ROI)

1 fixed region for main stream and sub-stream


Image Enhancement

BLC, HLC, EIS, Lens distortion,3D DNR

Image Setting

Saturation, brightness, contrast, sharpness, rotate mode, white balance, AGC

Day/Night Switch

Day/Night/Auto/Schedule

SNR

>/= 50 dB

Privacy Mask

4 regions of privacy mask

Network

Network Storage

micro SD/SDHC /SDXC (256 G) local storage, and NAS (NFS, SMB/CIFS), auto network

replenishment (ANR)

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket,

WebSockets

API

ONVIF (PROFILE S, PROFILE G), ISAPI, SDK

Security

Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest

authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2

Simultaneous Live View

Up to 6 channels

User/Host

Up to 32 users, 3 levels: administrator, operator and user

Client

iVMS-4200, GuardingVision, Hik-Central

Web Browser

Plug-in required live view: Chrome 45.0+, Firefox 52.0+

Plug-in free live view: Chrome 41.0+, Firefox 30.0+

Interface

Communication Interface

1 RJ45 10M/100M self-adaptive Ethernet port

On-board storage

Built-in micro SD/SDHC/SDXC slot, up to 256 GB

Hardware Reset

Yes

General

Web Client Language

32 languages

English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)

General Function

Privacy mask, heartbeat, mirror, flash log, password reset via e-mail, pixel counter

Startup and Operating

Conditions

-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)

Storage Conditions

-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)

Power Supply

12 VDC ± 25%; PoE (802.3at, class 4)

Power Consumption and Current

12 VDC, 0.6 A, max. 7.2W PoE: (802.3af, 36 V-57 V), 0.3 A to 0.2 A, max. 8.7W

Power Interface

5.5 mm coaxial power plug

Material

Metal

Dimensions

Camera: 105 × 278 mm (4.1 × 10.9)

With package: 386 × 156 × 155 mm (15.20× 6.14 × 6.10)

Weight

Camera: 570 g (1.26 lb.)

With package: 760 g (1.68 lb.)

Approval

Class

Class B

Protection

IP67

EMC

FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN

61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC

(ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)

Safety

UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-

1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)

Environment

CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
