55 LCD Splicing Display Unit
55 LCD Splicing Display Unit
Model: MW-A55-B1
Available in stock
* High reliability integration design
* Built-in image splicing function
* Support special splicing compensation
* Support screen to prevent cauterizing, image flip
* Support white balance adjustment
* Support remote control and RS232 hoop control
* Support record and display working time on panel
* Support fast splicing unit ID, convenient for adjustment
* Supports double frame function
* Power delay function after power
* Stable running and low maintenance cost, supporting 24 hours continuous working
Couldn't load pickup availability
| Model | MW-A55-B1 |
| Display | |
| Diagonal Size (inch) | 55? |
| Backlight | LED (Direct type) |
| Physical Seam | 3.5 mm |
| Resolution | 1920×1080 |
| Color | 16.7M |
| Brightness | 500 cd/m2 |
| Contrast | 4000:1 |
| Response Time | 8 ms |
| Viewing Angle | Horizontal 178°, Vertical 178° |
| Interface | |
| Input Interface | 1×VGA, 1×DVI, 1×HDMI |
| USB | 1×USB |
| Control Interface | 1×RS-232 IN, 1×RS-232 OUT, 1×IR |
| General | |
| Dimensions (W×H×D) | 1078.44mm×608.46mm×124.05mm |
| Power Supply | 100 to 240 VAC |
| Consumption | 136 W |
| Weight | 23.5 Kg |
| Operation Temperature | 0°C ~ 40 °C |
| Operating Humidity | 20%~90% (No Condensation) |
