MileSight MS-S0216-GL
MileSight MS-S0216-GL
Model: MS-S0216-GL
Regular price
$517.50
Sale price
$517.50
Regular price
Available in stock
Open here
* PoE Standard: IEEE802.3 af/at
* Port Lightning Protection: 4KV 8/20us
* Protection Level: IP30
Couldn't load pickup availability
- PoE Standard: IEEE802.3 af/at
- Port Lightning Protection: 4KV 8/20us
- Protection Level: IP30
- PoE Ports: 16X10/100; Mbps
- Uplink Ports: 2X1000; Mbps
- Max PoE Capacity: 200W
- Max PoE Power per Port: 30W
- Switching Capacity: 14.8; Gbps
- Extend Mode: √
| PoE Switch | |
|---|---|
| Model | MS-S0216-GL |
| Appearance | |
| Ports | 16X10/100Mbps PoE ports (RJ45) + 2X 1000Mbps uplink ports |
| Standard | IEEE802.3 10Base-T IEEE802.3i 10Base-T IEEE802.3u 100Base-TX IEEE802.3ab 1000Base-T IEEE802.3x |
| Switching Capacity | 14.8Gbps (non-blocking) |
| Packet Forwarding Rate@64byte | 5.36Mpps |
| Packet Forwarding Cache | 4M |
| MAC | 16K |
| Power Supply | Built-in switching power supply AC 100~240V, 50-60Hz, 2.5A |
| PoE Standard | IEEE802.3af/at |
| Max. PoE Power | Max. capacity: 200W Max. capacity for single port: 30W |
| Functional Switch | Standard Mode: Port 1~16: 10/100Mbps auto-sensing @100 meters & Port 17~18: 1000Mbps@100 meters Extend Mode: Port 1~8: 10/100Mbps auto-sensing@100 meters & Port 9~16: 10Mbps@250 meters & Port 17~18: 1000Mbps@100 meters Note: When the switch status changes, PoE switch must be restarted for the switch function to take effect. |
| Indicator | Power Indicator: PWR(green) Network Indicator: Link(yellow) PoE Working Indicator: PoE(green) Functional Switch Indicator: EXTEND(green) |
| Cooling Fan | 1 |
| Operating Temperature | -20°C~55°C |
| Storage Temperature | -40°C~75°C |
| Operating / Storage Humidity | 10% ~ 90%RH(non-condensing) |
| Lightning Protection/ Protection Level | Port lightning protection: 4KV 8/20us Protection level: IP30 |
| Dimensions | 270.4mm(W)X181mm(D)X44mm(H) |
| Weight | 1.5kg |
| Installation Method | Desktop Mounted Type, Wall Mounted Type |
