MileSight MS-N5016-NPE
MileSight MS-N5016-NPE
Model: MS-N5016-NPE
Regular price
$1,040.63
Sale price
$1,040.63
Regular price
Available in stock
Open here
Couldn't load pickup availability
- 1*RJ45 100/1000Mbps
- 2*USB 2.0 Interfaces
- 1*RCA Audio Input + 1*RCA Audio Output
- AI Based Video Content Analysis, Face Detection, ANR, PoS Integration, ANPR Management, Auto Backup
- Bandwidth: In:160Mbps; Out:160Mbps
- Synchronous Playback: 3*8MP; 4*5MP; 12*1080P; 16*720P
- PoE Ports: 16
- HDD Support: 2*10TB; (3.5”HDD)
- Alarm I/O: 4/1
| MS-N5016-PE | MS-N5016-NPE |
|---|---|
| Device | |
| Appearance | Appearance |
| 380mm(W)X317.6mm(D)X51.8mm(H)/2.6Kg Rack Mountable Chassis (1.0U Standard) | |
| 380mm(W)X317.6mm(D)X51.8mm(H)/2.7Kg Rack Mountable Chassis (1.0U Standard) | 380mm(W)X317.6mm(D)X51.8mm(H)/2.7Kg Rack Mountable Chassis(1.0U Standard) |
| Video/Audio Input | |
| 16-CH/16*PoE Ports | 16-CH/16*PoE Ports |
| Incoming/Outcoming Bandwidth | |
| 80Mbps/50Mbps | 160Mbps/160Mbps |
| Video/Audio Output | |
| 1-CH, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz, HDMI Supports Audio Output | 1-CH, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz, HDMI Supports Audio Output |
| VGA Output | |
| 1-CH, Resolution: 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz | 1-CH, Resolution: 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| Recording Resolution | |
| 8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/D1/VGA/CIF/QCIF | 8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/D1/VGA/CIF/QCIF |
| Synchronous Playback | |
| 1*(30fps @8MP), 2*(30fps @6MP), 2*(30fps @5MP), 3*(30fps @4MP), 4*(30fps @3MP), 6*(30fps @1080P), 12*(30fps @720P) | 3*(30fps @8MP), 4*(30fps @6MP), 4*(30fps @5MP), 5*(30fps @4MP), 8*(30fps @3MP), 12*(30fps @1080P), 16*(30fps @720P), 16*(30fps @D1) |
| Video/Audio Compression | |
| H.264+/H.264 | H.264+/H.264 |
| Audio Compression | |
| G.711/AAC/G.722/G.726 | G.711/AAC/G.722/G.726 |
| Sample Rate | |
| 8KHz/16KHz | 8KHz/16KHz |
| Storage | |
| 2*SATA HDD(3.5'') | 2*SATA HDD(3.5'') |
| Capacity | |
| Up to 10TB capacity for each HDD | Up to 10TB capacity for each HDD |
| Recording Management | |
| Continuous, Event (Motion Detection, Alarm, VCA, Smart Analysis) | Continuous, Event (Motion Detection, Alarm, VCA, Smart Analysis) |
| Playback | |
| General Playback, Event Playback, Tag Playback, Split Playback, Picture Playback | General Playback, Event Playback, Tag Playback, Split Playback, Picture Playback |
| Backup | |
| Video Backup, Image Backup | Video Backup, Image Backup |
| Network | |
| IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, NTP, SNTP, SMTP, SNMP, UPnP, NFS | IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, NTP, SNTP, SMTP, SNMP, UPnP, NFS |
| External Interface | |
| 1*RJ45 10/100/1000Mbps | 1*RJ45 10/100/1000Mbps |
| USB Interface | |
| 2*USB 2.0 | 2*USB 2.0 |
| Audio Input/Output | |
| 1*RCA/1*RCA | 1*RCA/1*RCA |
| Alarm Input/Output | |
| 4-CH/1-CH | 4-CH/1-CH |
| PoE Interface | |
| 16*RJ45 10 / 100Mbps | 16*RJ45 10 / 100Mbps |
| Power Output | |
| ≤200W | ≤200W |
| Supported Standard | |
| IEEE 802.3af/at | IEEE 802.3af/at |
| General | |
| Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Human Detection, People Counting, Object Left, Object Removed | Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Human Detection, People Counting, Object Left, Object Removed |
| Power Supply | |
| AC 100V~240V 50Hz~60Hz | AC 100V~240V 50Hz~60Hz |
| Consumption | |
| ≤8.5W (Without HDD, without enabling PoE) | ≤8.5W (Without HDD, without enabling PoE) |
| Working Conditions | |
| Temperature: -10°C~55°C / Humidity: 10%~90% | Temperature: -10°C~55°C / Humidity: 10%~90% |
