Technical Specification

Electronic Defog

Yes

Camera

Mirror

Off/On

Image Sensor

1/2.7 inch CMOS

Privacy Masking

Off/On (8 area, rectangle)

Effective Pixels

1920(H)×1080(V), 2MP

Certifications

Scanning System

Progressive

Certifications

CE (EN55032:2015, EN 61000-3-2:2014, EN 61000-

3-3:2013, EN55024:2010+A1:2015, EN 55035:2017, EN50130-4:2011+A1:2014)

FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Electronic Shutter Speed

PAL: 1/25s–1/100000s NTSC: 1/30s–1/100000s

S/N Ratio

>65dB

Port

Minimum Illumination

0.02Lux/F1.7, 30IRE, 0Lux IR on

Audio Output

One channel built-in mic (-A)

Fill Light Working Distance

60 m (196.9 ft)

Video Output

Video output choices of CVI/TVI/AHD/CVBS by one

BNC port

IR On/Off Control

Auto; manual

Power

IR LED Number

2

Power Supply

12V ±30% DC

Pan/Tilt/Rotation Range

Pan: 0°–360°

Tilt: 0°–78°

Rotation: 0°–360°

Power Consumption

Max 8.2W (12V DC, IR on)

Lens

Environment

Lens Type

Motorized vari-focal

Operating Temperature

-30°C to +60°C (-22°F to 140°F);<95% (non-

condensation)

Auto Focus

N/A

Storage Temperature

-30°C to +60°C (-22°F to 140°F);<95% (non-

condensation)

Mount Type

?14
