Camera

Image Sensor

1/2.8" CMOS

Pixel

4 MP

Max. Resolution

2560 (H) × 1440 (V)

Electronic Shutter Speed

1/1 s–1/30,000 s

ROM

4 GB

RAM

1 GB

Min. Illumination

Color: 0.005 lux@F1.6
B/W: 0.0005 lux@F1.6
0 lux (IR light on)

Illumination Distance

150 m (492.13 ft) (IR)
50 m (164.04 ft) (white light)

Illuminator Number

2 (IR light)
2 (dual light fusion)

Lens

Focal Length

4.8 mm–120 mm

Max. Aperture

F1.6–F3.5

Field of View

H: 55.8°–2.9°; V: 31.6°–1.6° ; D: 63.7°–3.3°

Optical Zoom

25×

Focus Control

Auto; semi-auto; manual

Close Focus Distance

0.8 m–5.0 m (2.62 ft–16.40 ft)

Iris Control

Auto; manual

DORI Distance

Detect

Observe

Recognize

Identify

1,655 m (5,429.79 ft)

653 m (2,142.39 ft)

331 m (1,085.96 ft)

165 m (541.34 ft)

PTZ

Pan/Tilt Range

Pan: 0° to 360° endless
Tilt: –20° to +90°, auto flip 180°

Manual Control Speed

Pan: 0.1°/s–160°/s

Tilt: 0.1°/s–60°/s

Preset Speed

Pan: 240°/s; Tilt: 150°/s

Preset

300

Tour

8 (up to 32 presets per tour)

Pattern

5

Scan

5

Power-off Memory

Yes

Idle Motion

Preset; Tour; Pattern; Scanning

PTZ Protocol

DH-SD
Pelco-P/D (auto recognition)

Intelligence

Video Metadata

Support human body, human face, motor vehicle and non-motor vehicle image capture.

IVS (Perimeter Protection)

Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc.

Face Detection

Yes

SMD

Yes

Auto Tracking

Yes

Active Deterrence

Light Warning

Red and blue warning light

Flash duration: 5 s–30 s

Flash frequency: High, medium, low

Sound Warning

Sound warning alarm: Customizable

Video

Video Compression

Smart H.265+; H.265; Smart H.264+; H.264B; H.264H; MJPEG

Streaming Capability

3 streams

Resolution

4M (2560 × 1440); 3M (2048 × 1536); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576); CIF (352 × 288)

Video Frame Rate

Main stream: 4M/3M/1080p/1.3M/720p (1–50/60 fps)

Sub stream 1: D1/CIF (1–25/30 fps)

Sub stream 2: 1080p/1.3M/720p (1–25/30 fps)

Bit Rate Control

CBR; VBR

Video Bit Rate

Default resolution of the main stream:
H264: 2816 kbps–8192 kbps
H265: 1024 kbps–7936 kbps

Day/Night

Auto (ICR); Color; B/W

BLC

Yes

WDR

120 dB

HLC

Yes

White Balance

Auto; manual; tracking; indoor; outdoor; outdoor auto; sodium lamp; sodium lamp auto

Gain Control

Auto; manual

Noise Reduction

2D NR; 3D NR

Motion Detection

Yes

Region of Interest (RoI)

Yes

Image Stabilization

EIS

Defog

Electric

Digital Zoom

16×

Privacy Masking

Up to 24 areas can be set, with up to 8 areas in the same view; supports multiple colors and mosaic blocks

S/N Ratio

>/= 55 dB

Audio

Audio Compression

G.711a; G.711Mu; G.726; G722.1; G.729; MPEG2-Layer2; G723; PCM

Network

Network Port

RJ-45 (10/100 Base-T)

Network Protocol

HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP;

DNS; DDNS; IPv6; 802.1x; SSL; QoS; FTP; UPnP; ICMP;

SNMP; SNMP v1/v2c/v3 (MIB-2); IGMP; ARP; RTCP; RTP;

PPPoE; IP Filter; RTMP; Bonjour; TCP; SMB; NFS

User/Host

20 (total bandwidth: 64 M)

Interoperability

ONVIF (Profile S&G&T)

Storage

FTP; Micro SD card (256 GB); NAS

Browser

IE 7 and later versions
Chrome 42 and earlier versions
Firefox 52 and earlier versions
Safari

Management Software

Smart PSS; DSS; DMSS; Easy4ip; IVSS; player; configtool; NVR; Smart Player

Mobile Client

iOS; Android; iPhone; iPad; Windows Phone

Certification

Certifications

CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014

Port

Audio Input

1 (LINE IN; bare wire)

Audio Output

1 channel (LINE OUT, bare wire; built-in speaker (mutually exclusive))

Alarm Input

2-ch, digital input (0–5 VDC)

Alarm Output

1-ch

Alarm Linkage

Capture; preset; tour; pattern; recording; alarm digital input; send email

Alarm Event

Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection

Power

Power Supply

24 VDC, 2.5 A (± 25%) (included)
PoE+ (802.3at)

Power Consumption

Basic: 13 W
Max.: 23 W (illuminator + red and blue warning light+speaker + PTZ working)

Environment

Operating Temperature

–40 °C to + 70 °C (–40 °F to + 158 °F)

Operating Humidity

</= 95%

Protection

IP66; TVS 6000 V lightning proof; surge protection;

voltage transient protection

Structure

Casing

ADC12

Product Dimensions

325.3 mm × ?202.0 mm (12.81" × ?7.95") (H × D)

Net Weight

4.6 kg (10.14 lb)

Gross Weight

9.1 kg (20.06 lb)
