Galaxy Wired GPS Tracking Device (Monthly service fee extra: GX-GPS-SERVICE)
Galaxy Wired GPS Tracking Device (Monthly service fee extra: GX-GPS-SERVICE)
Model: GX-GPS-WIRED
Available in stock
GX-GPS-WIRED is a cost effective device for where basic tracking is required. It does come in a variety of configurations allowing for sensor inputs, temperature, driver ID, voltage measurement (ADC) as well as RS232. Installation required. Monthly service fee is required.
Couldn't load pickup availability
- Applications : Vehicle Tracking / Recovery / FMS / Logistics
- Memory buffer report up to 10,000
- LTE Cat M1/NB-IoT/2G
- Variable options (ST4310U/W/R/RW/M)
- Jamming Detection (Optional)
- Configurable Report Formats
- DPA (Driving Pattern Analysis) *Optional
- CR (Crash Reconstruction) *Optional
- Circular / Poliygonal Geofencing
- Waterproof IP67 Compliant
- Installation required
- Monthly service fee is required.
| Wireless Comunication | |
| Network frequency | LTE Cat M1/ NB-IoT |
| 2G | |
| GNSS | |
| Receiver Type | GPS, GLONASS SBAS: WAAS, EGNOS, MASA |
| Location Accuracy | Autonomous < 2.5m CEP |
| Update Rate | 1Hz |
| Cold Start | <35s |
| Warm Start | <30s |
| Hot Start | <1s |
| Tracking Sensitivity | Tracking -167dBm |
| Reacquisition -161dBm | |
| Acquisition -149dBm | |
| Physical | |
| Dimension | 94(L) x 55(W) x 23(T) mm |
| Weight | 103g (with event cable) |
| Hardware | |
| I/O | 1 Ignition/Input (Configurable) |
| 1 Input for panic button, door sensor | |
| 2 Outputs for vehicle blocking, open drain, siren | |
| 1-Wire, RS232, ADC, External power (Optional) | |
| LED Indicator | Network, GPS |
| Antenna | Internal |
| Accelerometer | Built-in 3-axis accelerometer |
| Battery/Power | |
| Back-up Battery | Rechargeable 3.7V, 220mAh (Li-ion) |
| Power Supply | DC 8 ~ 33 V |
| Power Consumption | Active mode: 70~80mA @12V |
| Sleep mode: Approx. 4mA @12V | |
| Deep Sleep mode: Approx. 2mA @12V | |
| Environmental | |
| Temperature Range | -40deg.C ~ +80deg.C |
| Dust and Water Resistant | IP67 |
| Certificates | FCC, PTCRB, IC |
