Interface

2-Wire

1 x 2-Pin Terminal Block-Ethernet over 2-Wire (T-LinX)

Ethernet

1 x RJ45 - 10/100 Base-T with Auto-detect MDIX

Transmission Rate

95Mbps Full Duplex

(270Mbps between Intercoax 2 series models)

Transmission Distance

2-Wire

up to 600 m(Twisted Pair Cable/Cat.5e)

PoE (PoC)

up to 300 m (Cat.5e / 7W camera)

LED

Indication

Ethernet

1 x Data-Link (Yellow)

Data over 2-Wire

1 x Join-Link (Green)

Power

1 x Power On (Amber)

PoE Output

1 x PoE Out (Red)

Encryption

128-bit AES

Power

Input

T-Linx or DC12V~57V

PoE Switch or DC48V~57V

PoE Output

IEEE802.3af(PoE), IEEE802.3at (PoE+),

Extra PoE up to 60W

PoE Not Supported Power Over 2-Wire Only

PoE Input

Not Supported

Up to 25.5W (PD)

Mechanical

Dimension

80.4(L) x 61.6(W) x 24(H)mm

Weight

102g

Environment

Operating Temp

-20 ~ 60°C

Storage Temp

-30 ~ 80°C

Relative Humidity

10% ~ 90%

Compliance

Certification

FCC, CE, KC, RoHS

Surge Protection

IEC 61000-4-5 4kV(1.2 / 50us), 2kA(8 / 20us)

Optional Accessories

57VDC / 1.2A External Power Supply
