Interface

Coax

1 x 75 Ohm BNC (Female) - Ethernet over Coax

Ethernet

1 x RJ45 - 10/100 Base-T with Auto-detect MDIX

Transmission Rate

95Mbps Full Duplex

(270Mbps between Intercoax devices)

Transmission Distance

Data

up to 2.4Km(RG-G)

PoE (PoC)

up to 1.2Km (RG-G / 7W camera)

LED Indication

Ethernet

1 x Data-Link (Yellow)

EoC

1 x Join-Link (Green)

Power

1 x Power On(Amber)

PoE

1 x PoE Out (Red)

Encryption

128-bit AES

Power

Input

ECP-2G01R or DC48V~57V

PoE Output

IEEE802.3af (PoE), IEEE802.3at (PoE+),

Extra PoE up to G0W with 57V Power Adaptor

Mechanical

Dimension

82.4(L) x G1.G(W) x 24(H)mm

Weight

77g

Environment

Operating Temp

-20 ~ G0°C

Storage Temp

-30 ~ 80°C

Relative Humidity

10% ~ 90%

Compliance

Certification

FCC, CE, KC, RoHS

Surge Protection

IEC G1000-4-5 4kV(1.2 / 50us), 2kA(8 / 20us)

Optional Accessories

57VDC / 1.2A External Power Supply
