Camera

Image Sensor

1/3" Smartsens SC4336P CMOS

Soc Chip

Sigmastar SSC377

Effective Pixels

2560(H)×1440 (V)

Exposure Shutter

AUTO/Manual: 1/10s ~ 1/8000s, Max. Shutter speed adjustable

Day/Night

Auto(Active/passive/schedule)/Day/Night, switch threshold, sensitivity

Image Adjust

Brightness,Saturation,Sharpness,Contrast,Denoise (0-100%) adjustable

White Balance

AWB/MWB

WDR

No

Light Mode

Smart(dual-light) / IR / White light, adjustable

Light Control

Auto/Manual, Brightness level (0-100%) adjustable

DNR

2D/3D DNR

Encode

Video Standard

H.264/H.265

Video Resolution

Main Stream:
25fps@4MP(2560x1440)(default)/3MP(2304x1296)/1080P

Sub stream: 25fps@QVGA(640x360)(default)/CIF(352x288)

Video Bitrates

Sub stream: 64kbps-8Mbps
Sub stream: 64kbps-2048kbps
VBR/CBR , quality(1-9), GOP(1-128)

Image Rotation

No

Border Crop

X crop, Y crop

Image Mirror

horizon / vertical / horizon&vertical adjustable

OSD Overlay

Font size(1-4), position,Time, Title, AM/PM, Color, User OSD, Alarm OSD

Privacy Mask

4 areas

Region of Interest

ROI: Each stream support 8 areas

Audio Standard

G.711-u/G.711-a/AAC/PCM, AEC

Built-in Mic

Yes

Built-in Speaker

(optional)

Led

IR Led

2pcs

White Led

2pcs

Distance

30M

Lens

Focal length

F1.6 2.8/3.6 mm fixed

Language

English, simplified Chinese, Chinese Traditional, Korean, Russian, etc.

Smart Detection

Motion Detection

Yes

Digital IO Alarm

1 pair Alarm-in/Alarm-out, normally open/normally close

Human Vehicle Detection

support

Cross Line Detection

Yes

Perimeter protection

No

Face Detection

No

Target Detection Type

Human Shape, vehicle, non-motor vehicle, Pet

Trigger Action Linkage

Snapshot, Record, Relay(Red-blue Led flash), White LED Flash, Voice siren

Micro-SD, Email, FTP

Simultaneous Detection

Maximum 16 targets simultaneous detection

Storage Type

Schedule/Trigger: Micro-SD(512G) , Email, FTP

Network Services

Protocol

HTTP(s)/RTSP/FTP/SMTP/DHCP/NTP/DST/RTP/RTMP/P2P/HiK/IPv4

P2P Mobile APP

Android, IOS

Web Access

IE, Firefox, Chrome, Edge, Safari, etc.

PC Tool

Windows, Mac

ONVIF

16.12 compatible (profile S G T M)

General

Network Port

1-RJ45, 100Mbps, POE optional

Power Supply

12 VDC ± 10%

Power Consumption

< 8 W

Operating Temp.

-20C-(+60)C, 10%-90%RH
