Galaxy CV Series NDAA 8MP/4K
Galaxy CV Series NDAA 8MP/4K
Model: GX-CV728P-AI-DL-28A
Regular price
$317.55
Sale price
$317.55
Regular price
Available in stock
🖨️ Print as PDF
×
Send a copy to email:
Open here
Galaxy CV Series NDAA 8MP/4K Panoramic Dual Lens Dual Light AI POE IPC with Two Way Audio / 2x 4MP Dual Cameras / D-WDR / AI Human & Vehicle Detection / H.265+ / Build in Mic and Speaker / 30 Meters IR Distance / 2x 2.8mm lens / SD Card slot support up to 512GB / Optional Junction Box: GX-CV-BK99X / Wall Mount: GX-CV-BK99D / AI Plug and Play compatible with CV and UNV NVRs / Hikvision Hilook NVRs only support onvi
Couldn't load pickup availability
- 1/2.7" CMOS sensor
- 8MP wide-view resolution 4096 x 1944P (19:9)
- 180 °wide-angle
- Low illumination 0.01Lux
- Day/Night, AWB/MWB, BLC, HLC, 2D/3D-DNR, Shutter, ? D-WDR, Mirror , Defogging
- Multiply Style OSD Overlay, Motion Detection, Privacy Mask
- RTSP and Onvif 17.06 compatible with many third-party NVR
- H.264/H.265 dual-stream media server
- Easy-to-use P2P Cloud service
- Support user authentication, video data encryption
- Support Alarm Snapshot to Email and FTP
- Multiply WEB browser IE,Firefox 32bit ESR, Edge,Google Chrome,PC Client, Mobile APP remote access
- RJ45 100mbps network port, IEEE802.3af PoE
- Lightning protection 4000V
- Strong water-proof housing, IP66
- 2pcs Warm light + 3pcs IR Array leds, IR/White light distance:25-30M,
- Three light Modes:
- Mode 1: Smart Dual Light
- Mode 2: Pure Infrared Light
- Mode 3: Pure White Light
- 2*F1.6 2.8
| Camera | |
| Image Sensor | 1/2.7" GC5623 CMOS x2 |
| Effective Pixels | 8 megapixels |
| Electronic Shutter | AUTO, 1/25s ~ 1/100000s |
| Min. Illumination | 0.01Lux@F1.2(AGC ON) |
| Day/Night | Auto/Color/(B/W)/Timing |
| WDR | Digital WDR |
| White Balance | Auto/Manual |
| BLC /HLC | Support |
| DNR | 2D/3D DNR |
| Other | Human body and Vehicle detection ,AGC,Motion Detection,Privacy Mask,Flip ,OSD overlay |
| Encode | |
| Video Standard | H.264/H.265/H.265+ |
| Video Resolution | MainStream:20fps@4096x1944P |
| Sub stream: 20fps@1024x480 | |
| Video Bitrates | 512Kbps - 8Mbps, VBR/CBR |
| Audio Standard | G.711-u/G.711-a/AAC |
| Built-in Mic | Yes |
| Built-in Speaker | Yes,Two-way audio |
| Smart Detection | Human body and Vehicle Detection |
| Led and distance | |
| Led | 2pcs warm-light Led + 3pcs IR Array Led |
| IR Distance | 20-30 M |
| White light Distance | 20-30 M |
| Lens | |
| Focal length | 2*F1.6 2.8 mm fixed lens |
| FOV | 180° |
| Other FunctionS | |
| With SD card slot ,support UP to 512GB SD card,with reset button | |
| Network Services | |
| Protocol | HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS, etc. |
| P2P | Yes |
| Web | IE , Firefox,Edge, Google Chrome etc. |
| Media | CMS, Android, IOS |
| ONVIF | 17.06 compatible |
| General | |
| Network Port | 1-RJ45, 100Mbps, POE optional |
| Power Supply | 12 VDC ± 10% |
| Power Consumption | < 10 W |
| Operating Temp. | -30C-(+60)C, 10%-90%RH |
