Speaker

Rated Power

70 V:  5 W/10 W/15 W/20 W

100 V:  5 W/10 W/15 W/20 W

Impedance

8 OHM

Sensitivity(1 m, 1 W)

90 dB ± 3dB

Max. Acoustic Pressure

103 dBSPL

Direction

All directions

Frequency Response

130 Hz to 17.5 kHz

Speaker Unit

5.25?? ×     1

Interface

Audio In

Fixed pressure in 100 V/Fixed pressure in 70 V/Fixed resistance input 8 OHM × 1

General

Material

Main body&Front cover?plastic, bracket: metal

Operating Temperature

-30 °C to 60 °C (-22 °F to 140 °F)

Operating Humidity

?90% (No condensation)

Dimension

268.4 mm × 180.4 mm × 125.12 mm (10.57" × 7.1" × 4.93")

Package Dimension

340 mm × 306 mm × 180 mm (13.39" × 12.05" × 7.09")

Weight

Approx. 1.5 kg (3.3 lb.)

Color

White

With Package Weight

Approx. 2 kg (4.4 lb.)

Packing List

Device × 1

U-shaped bracket × 1 Screw pack × 1 Installation sticker × 1

Regulatory Compliance and Safety Information × 1
