Galaxy DH 16CH Full D1 DVR Capture Board - PCI Express
Galaxy DH 16CH Full D1 DVR Capture Board - PCI Express
Model: DG4216HF-E
Regular price
$652.50
Sale price
$652.50
Regular price
Available in stock
🖨️ Print as PDF
×
Send a copy to email:
By entering your email, you agree that it will be seen by store and may contact you.
Open here
H.264, full D1 realtime live view, 16CH full D1 video realtime compression, dual-stream, 16CH G.711 audio compression, motion detection, OSD, logo overlay, TV or VGA output, PCI-Express, compatible with all DG/NV compression cards
Couldn't load pickup availability
- Audio and video hardware compression card, using advanced standard H.264 video compression algorithm to achieve excellent image quality and high compression ratio
- Support up to full D1 realtime live view
- 16 channel full D1 video realtime compression, support dual-stream
- 16 channel G.711 audio compression
- Support motion detection, video loss and camera masking function; support OSD, logo overlay, video frame rate, frame rate dynamic setup and etc
- Support Windows 2000/XP/2003/Vista/7
- Support TV or VGA output with multi split and tour display
- Standard PCI-Express 1.0 (1X), compatible with all DG/NV compression cards
| Video Format | PAL and NTSC |
| Video Input | 16 Ch BNC (1.0Vp-p, 75ohm) |
| Audio Input | 16 channel, BNC(2.0Vp-p 1000ohm) |
| Video output | 2 channel TV(BNC)/2 channel VGA(Extension) |
| Preview Resolution | 704*576(PAL),704*480(NTSC), Realtime |
| Video Compression | H.264, Support CBR, VBR Frame: 25F/s(PAL),30F/s(NTSC) Output: 32k~2M bps (CIF), 70K~4M bps (4CIF) Per Channel |
| Compression Resolution | 4CIF:704*576(PAL), 704*480(NTSC) Half-D1:352x576(PAL), 352x480(NTSC) 2CIF:704*288(PAL), 704*240(NTSC) CIF:352*288(PAL), 352*240(NTSC) QCIF:176*144(PAL), 176*120(NTSC) |
| Audio Compression | PCM(G.711) |
| Sampling Rate | 8KHz |
| Audio Bit Rate | 64Kbps |
| Power Consumption | 12 W |
| Working Environment | -10°C~+55°C/10~90%RH/86~106kpa |
| Dimension | 175mm x 106.6mm |
