Power Supply: 12 V DC (±10 %)
Supplied with a standard 110~240V AC to 12V DC power module
Multi-channel monitoring: Supports 12 current channels and 3 voltage
channels for comprehensive measurement.
High measuring accuracy with a sampling frequency of up to 8 kHz.
Flexible configuration: Each current channel can be set independently for
12 single-phase or grouped for up to 4 three-phase circuits.
Compatible with split-core CTs (100A/300A/500A/1000A) and Rogowski
coils.
Supports external wire temperature sensor for cable temperature
monitoring.
Remote configuration and data reading via Bluetooth Toolbox App.
Built-in LoRaWAN® and Bluetooth for seamless integration and local
configuration.
Supports Firmware-Update-Over-The-Air (FUOTA).
Stores up to 12 months of energy data and event logs.
User-defined threshold alarms and device-initiated overload/out-of-range
alarms.
Compliant with IEC 62053-21/23 standards.
IP30 rated
