Camera

Image Sensor

5 megapixel progressive scan CMOS

Signal System

PAL/NTSC

Resolution

2560 (H) × 1944 (V)

Min. Illumination

Color: 0.003 Lux @ (F1.2, AGC ON), 0 Lux with IR

Frame Rate

TVI: 2MP@25fps, 2MP@30fps, 4MP@25fps, 4MP@30fps, 5MP@20fps

AHD: 4MP@25fps, 4MP@30fps, 5MP@20fps

CVI: 4MP@25fps, 4MP@30fps

CVBS: PAL, NTSC

Shutter Time

PAL: 1/25s to 1/50, 000 s

NTSC: 1/30 s to 1/50, 000 s

Lens

2.7 mm to 13.5 mm motorized varifocal lens

Horizontal Field of View

92.3° to 29.3°

Lens Mount

 14

Day & Night

IR cut filter

Angle Adjustment

Pan:0° to 360°; Tilt: 0° to 90°; Rotate:0° to 360°

Synchronization

Internal synchronization

WDR (Wide Dynamic Range)

>/=130 dB

Menu

AGC

Yes

Day/Night Mode

Auto/Color/BW(Black and White)

White Balance

Auto/Manual

BLC (Backlight Compensation)

Yes

WDR

Yes

3D DNR

Level 1 to 9

Privacy Mask

4 programmableprivacy masks

Motion Detection

4 programmable areas

Language

English

Functions

Brightness, Sharpness, 3D DNR, Mirror, Smart IR

Interface

Video Output

1 HD analog output

Switch Button

TVI/AHD/CVI/CVBS

General

Operating Conditions

-40 °C to 60 °C (-40 °F to 140 °F),humidity: 90% or less (non-condensing)

Power Supply

-A: 9.6 VDC to 14.4 VDC; 19.2 VAC to 28.8 VAC

Power Consumption

-A: Max. 10.5 W

Protection Level

IP67

Material

Metal

IR Range

Up to 80 m

Communication

Up the coax, Protocol: HIKVISION-C(TVI output)

Dimensions

84.5 mm × 92 mm × 255.1 mm (3.33 × 3.62"× 10)

Weight

Approx. 930 g (2.05 lb.)
