Camera

Image Sensor

8.29 MP CMOS

Max. Resolution

3840 (H) × 2160 (V)

Min. Illumination

0.01 Lux@(F1.2, AGC ON), 0 Lux with IR

Shutter Time

PAL: 1/12.5 s to 1/50, 000 s

NTSC: 1/15 s to 1/50, 000 s

Day & Night

ICR

Angle Adjustment

Pan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360°

Signal System

PAL/NTSC

Lens

Lens Type

2.8 mm, 3.6 mm, 6 mm fixed lens

Focal Length & FOV

102.9° (2.8 mm), 79° (3.6 mm), 44.7° (6 mm)

Lens Mount

M12


Image Parameters Switch

STD/HIGH-SAT

Image Settings

Brightness, Sharpness, Smart IR

Frame Rate

TVI: 8MP@12.5fps, 8MP@15fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, 2MP@30fps AHD: 8MP@15fps

CVI: 8MP@12.5fps, 8MP@15fps

CVBS: PAL/NTSC

Day/Night Mode

Auto/Color/BW (Black and White)

Wide Dynamic Range (WDR)

Digital WDR

Image Enhancement

Global, BLC, HLC

White Balance

Auto/Manual

AGC

Yes

Noise Reduction

2D DNR

Interface

Video Output

Switchable TVI/AHD/CVI/CVBS

General

Material

Enclosure: Plastic

Main body: Metal

Dimension

Ø 109.82 mm × 91.03 mm (4.32" × 3.6")

Weight

Approx. 315 g (0.69 lb.)

Operating Condition

-40 C to 60 C (-40 F to 140 F), humidity: 90% or less (non-condensation)

Communication

HIKVISION-C

Language

English

Power Supply

12 VDC ± 25%

*You are recommended to use one power adapter to supply the power for one camera.

Consumption

Max. 2.9 W

IR Range

Up to 60 m
