• High quality imaging with 4 MP resolution
  • Realizing Wi-Fi connection and easy installation
  • Provides real-time security via built-in two-way audio
  • Efficient H.265 compression technology
  • EXIR 2.0, advanced infrared technology with long IR distance
  • Wi-Fi connection with Hik-Connect directly is not possible
  • Water and dust resistant (IP66)
  • Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
  • Camera
  • Image Sensor1/3" Progressive Scan CMOS
  • Max. Resolution2560 × 1440
  • Min. IlluminationColor: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
  • Shutter Time1/3 s to 1/100,000 s
  • Day & NightIR cut filter
  • Angle AdjustmentPan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°
  • Lens
  • Lens TypeFixed focal lens, 2.8 and 4 mm optional
  • Focal Length & FOV

    2.8 mm, horizontal FOV 95°, vertical FOV 53°, diagonal FOV 111°

    4 mm, horizontal FOV 79°, vertical FOV 40°, diagonal FOV 94°

  • ApertureF1.6
  • Iris TypeFixed
  • Lens MountM12
  • Depth Of Field

    2.8 mm: 1.4 m to Inf

    4 mm: 1.5 m to Inf

  • DORI
  • DORI

    2.8 mm, D: 63 m, O: 25 m, R: 12 m, I: 6 m

    4 mm, D: 78 m, O: 31 m, R: 15 m, I: 7 m

  • Illuminator
  • Supplement Light TypeIR
  • Supplement Light RangeUp to 30 m
  • Smart Supplement LightYes
  • IR Wavelength850 nm
  • Video
  • Main Stream

    50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720)

    60 Hz: 20 fps (2560 × 1440), 30 fps (1920 × 1080, 1280 × 720)

  • Sub-Stream

    50 Hz: 25 fps (1280 x 720, 640 × 480, 640 × 360)

    60 Hz: 30 fps (1280 x 720, 640 × 480, 640 × 360)

  • Video Compression

    Main stream: H.265+/H.265/H.264+/H.264

    Sub-stream: H.265/H.264/MJPEG

  • Video Bit Rate32 Kbps to 8 Mbps
  • H.264 TypeBaseline Profile,Main Profile,High Profile
  • H.265 TypeMain Profile
  • Bit Rate ControlCBR,VBR
  • Audio
  • Audio CompressionG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
  • Audio Bit Rate64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
  • Audio Sampling Rate8 kHz/16 kHz
  • Environment Noise FilteringYes
  • Network
  • ProtocolsTCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, QoS, IPv6, Bonjour
  • Simultaneous Live ViewUp to 6 channels
  • APIOpen Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK
  • SecurityPassword protection,complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS
  • User/HostUp to 32 users. 3 levels: administrator, operator and user
  • Network Storage

    NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),

    Together with high-end Hikvision memory card, memory card encryption and health detection are supported.

  • Client

    Wired network: Hik-Connect, iVMS-4200

    Wi-Fi: iVMS-4200

    *Wi-Fi connection with Hik-Connect directly is not possible.

  • Web Browser

    Plug-in required live view: IE 10+

    Plug-in free live view: Chrome 57.0+, Firefox 52.0+

    Local service: Chrome 57.0+, Firefox 52.0+

  • Wi-Fi
  • Wi-Fi Protocol802.11n: OFDM,802.11b: CCK, QPSK, BPSK,802.11g: OFDM
  • Frequency Range2.412 GHz to 2.472 GHz
  • Channel Bandwidth20/40 MHz
  • Modulation802.11n: OFDM ,802.11b: CCK, QPSK, BPSK,802.11g: OFDM
  • Transfer Rate11n: up to 300 Mbps
  • Wireless Range

    Up to 120 m

    (The performance varies based on actual environment)

  • Antenna2 Antennas
  • Image
  • Image Settingssaturation, brightness, contrast, sharpness, adjustable by client software or web browser
  • Day/Night SwitchAuto, Schedule, Day, Night
  • Wide Dynamic Range (WDR)120 dB
  • SNR>/= 52 dB
  • Image EnhancementBLC, 3D DNR
  • Interface
  • Built-In MicrophoneYes
  • Built-In SpeakerYes
  • On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
  • Reset KeyYes
  • Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
  • Event
  • Basic EventMotion detection, exception
  • Linkage

    notify surveillance center,trigger recording,trigger capture,

    Upload to NAS/memory card

  • General
  • Power12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug,reverse polarity protection,A switching adapter is included in the package.
  • LanguageEnglish, Ukrainian
  • Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • General FunctionAnti-banding, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
  • Startup And Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • MaterialPolycarbonate cover, polycarbonate body
  • Dimension

    Ø126 mm × 96.1 mm (Ø5 × 3.8\")"

  • Package Dimension170 mm × 170 mm × 150 mm (6.7" × 6.7" × 5.9")
  • Approx. 590 g (1.3 lb.)
  • With Package WeightApprox. 989 g (2.2 lb.)
  • Approval
  • EMC

    FCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); IC VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)

  • RF

    FCC ID (FCC Part 15.247(BT or 2.4G));

    IC ID (RSS-247(BT or 2.4G));

    CE-RED (EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1(BT or 2.4G); EN 300328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G));

    MIC (JPN)

  • Safety

    UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);

  • Environment

    CE-RoHS: 2011/65/EU,

    WEEE: 2012/19/EU,

    Reach: Regulation (EC) No 1907/2006

  • ProtectionIP66: IEC 60529-2013
